Therma-Stor 200 MAX Installation Instructions

Items included with kit:
4 brackets,  shield
Tools needed:
5/6" nut driver/wrench
3
Remove and save bottom 2 screws. Place
mounting bracket in correct position for
lower track and install using existing
screws. Repeat on opposite side.
Toll-Free -800-533-7533 Toll-Free -800-533-7533
P . O. Box 8680
Madison, WI 53708
www.thermastor.com
200 MAX and 200 HT Shield

Installation Instructions

Read and Save These Instructions
1
Shield
Bottom bracket
position
Bracket orientation to create top and
bottom tracks
4
Slide shield over the track and push shield towards unit.
Phone 608-222-530
Toll-Free -800-533-7533
sales@thermastor.com
Shield
Unit Wall
Top bracket
position

2
Remove and save rear 2 of 3 top screws.
Place mounting bracket in correct position
for upper track and using existing screws.
Repeat on opposite side.
www.thermastor.com • sales@thermastor.com www.thermastor.com • sales@thermastor.com
TS-379
Revised 1/07
Top
placement
Bottom
placement
