Cable Connections, Ports, and Usage Scenarios
Reference Port
Number
1 HDCI line-out
2 HDMI line-out
3 HDMI line-in
4 USB 2.0 Type B
Polycom, Inc.
Cable Connection
Details
HDCI Polycom Connect the
EagleEye IV Digital mini-HDCI
camera cable cable from
the camera
out to the
RealPresenc
e Group
Series
system.
HDMI cable Connect the
display
monitor to
the camera's
HDMI line-
out port.
HDMI cable Connect the
computer's
HDMI line-
out port to
camera's
HDMI line-in
port.
USB cable Connect the
computer's
USB A port
to the
camera USB
2.0 B port.
Setting Up Your Camera
Usage Scenarios
Scenario 1: Use a
single camera with
a RealPresence
Group Series
system.
Scenario 2: Use a
primary camera
with a
RealPresence
Group Series
system for
cascading.
Scenario 1: Use
the EagleEye
Director II camera
as a display and to
by-pass video and
audio. At the same
time, the camera
receives a copy of
far-end audio as a
reference.
Scenario 1: Use
the EagleEye
Director II camera
as a display and to
by-pass video and
audio. At the same
time, the camera
receives a copy of
far-end audio as a
reference.
Scenario 1: Use a
single camera with
a local computer.
Scenario 2: Use a
primary camera
with a local
computer for
cascading.
