INSTALLATION AND MAINTENANCE INSTRUCTIONS
B401BR750 Plug-in Detector Base
For use with the following smoke detectors:
1451, 2451, and 2451TH
Specifications
Base Diameter:
Base Height:
Weight:
Mounting:
Operating Temperature Range:
Operating Humidity Range:
Electrical Ratings — includes base and detector
System Voltage:
Maximum Ripple Voltage:
Start-up Capacitance:
Standby Ratings:
Alarm Ratings:
Reset Voltage:
Reset Time:
Start-up Time:
Before Installing
Please thoroughly read the System Sensor manual I56-407,
Guide for Proper Use of System Smoke Detectors, which
provides detailed information on detector spacing, place-
ment, zoning, wiring, and special applications. Copies of
this manual are available at no charge from System Sensor.
(For installations in Canada, refer to CAN4-S524, Standard
for the Installation of Fire Alarm Systems, and CEC Part 1,
Sec. 32.)
NOTICE: This manual should be left with the owner/user
of this equipment.
IMPORTANT: The detector used with this base must be
tested and maintained regularly following NFPA 72 require-
ments. The detector used with this base should be cleaned
at least once a year.
D450-09-00
6.2 inches (157 mm)
1.1 inches (29 mm)
0.3 lb. (130 g)
4-inch square box with or without plaster ring. Min. Depth–1.5 inches
4-inch octagon box. Min. Depth–1.5 inches
3-1/2 inch octagon box. Min. Depth–1.5 inches
0° to +49°C (32° to 120° F)
10% to 93% Relative Humidity, noncondensing
12/24 VDC
4 Volts peak to peak
0.02 µ F Maximum
17 VDC Minimum; 32 VDC Maximum
120 µ A Maximum
10mA Minimum at 13.5 VDC; 39mA Maximum at 32 VDC
(If used, the RA400 remote lamp operates within specified detector alarm currents.)
2.5 VDC Minimum
0.3 Seconds Maximum
34.0 Seconds Maximum
General Description
The B401BR750 plug-in detector base is used with System
Sensor model 2451 and 2451TH photoelectronic detector
heads and model 1451A ionization detector heads. The ca-
pability of plugging these detectors into a variety of special
bases makes them more versatile than equivalent direct-
wired models. Refer to the System Sensor catalog for other
available plug-in detector bases.
This base is intended for use in 2-wire systems, with screw
terminals provided for power, ground, and remote annun-
ciator connections. It also contains a resistor to provide
current limiting in the alarm state.
1
A Division of Pittway
3825 Ohio Avenue, St. Charles, Illinois 60174
1-800-SENSOR2, FAX: 630-377-6495
I56-451-02
