In this mode, the MEM button becomes the START button on the web interface because the
readings are recorded automatically according to the recording frequency you need (Interval field
in the Settings menu: every second, every five seconds, etc.). To start the recording, click on this
icon or press the MEM button of the probe. The MEM button is not used to record one reading at
a time in this mode. When the recording is activated, the START button turns to the STOP button.
Click on STOP or press the MEM button to stop the recording.
3: MEM number
This number corresponds to the number of the last saved reading. Each saved reading and/or
marked point (stamp) is associated to a memory number.
4: STAMP icon
Use this icon or the STAMP button of the probe to mark a position. The positions marked will
allow you to create an accurate graph with your data on your personal computer. The more marks
that you have, more precise the graph will be (in Microsoft Excel software or else). The positions
to be marked are defined with the starting Depth and the Spacing of the Settings menu. The
Stamp icon indicates the point where the next mark must be done.
5: Depth section
This section shows the interval of the depth where the readings are currently recorded. The first
point of the first interval is the starting Depth set in the Settings menu. The second point of the
first interval is the next point to be marked (stamp) according to the Spacing set in the Settings
menu. After each Stamp, the depth increases according to the Spacing set in the Settings menu.
Then, the first point of the following intervals corresponds to the last Stamp and the second point
of the following intervals corresponds to the next point to be marked (stamp).
Last Stamp
(or starting Depth for
the first interval of
Instrumentation GDD inc.
the file)
OR
2017-08-21
Next
Stamp
