I
NSTALLATION

LED Indicators

Verify Status
Check the power and port LED indicators.
LED
Power
Ethernet
(4 LEDs)
ADSL Syn
ADSL Data
2-4
Condi- Status
tion
On The Barricade is receiving power. Normal
operation.
Off Power off or failure.
On Ethernet Link.
Flashing Sending/Receiving data.
Off No Link.
On ADSL connection is functioning correctly.
Flashing Startup.
Off ADSL connection is not established.
Flashing Sending/Receiving data.
Off No data transferring.
