INSTALLATION
2.2

Filling the Water Reservoir

Before operation the water reservoir located on the front panel must be fi lled with
distilled water (supplied with the instrument).
Use the fi lter bottle supplied to fi ll the water reservoir.
1. Remove the red plastic cap from the top of the reservoir.
2. Carefully fi ll with clean distilled water to a level between the two indicator
lines.
3. Replace the red cap on the water reservoir after fi lling.
6
Do not use tap water or demineralized water!
Figure 5
Do NOT fi ll above the MAX indicated line as this may cause liquid
to enter the humidity chamber and adversely affect the control
OptiCal User's Manual
Filling the Water Reservoir
process.
