SETUP
The setup menu contains less frequently used adjustments that
may be required during installation (e.g. On Screen Display
language selection or the display of Test Patterns).
ORIENTATION
Select the option that best describes the installation i.e. desktop
front, ceiling front, desktop rear and ceiling rear..
HORIZONTAL/VERTICAL KEYSTONE
To obtain maximum quality of the projected image, we recom-
mend the installation of the projector on a level platform parallel
and central to the screen.
Adjust the feet underneath to obtain a level position, lining up
the base of the projected image to the base of the projection
screen (Fig. 32).
If the projected images needs to be centred horizontally, the
manual lens shift adjustment allows the projected image to be
moved vertically, up or down, in relation to the centre of the
screen; the maximum adjustment being equal to half the height
of the image in either direction (Fig. 33).
In the event you are unable to centre the image within the
screen area, tilt the projector until the image is correctly posi-
tioned. Any keystone error can be removed by the Keystone
adjustment in the Set up menu. The keystone adjustement
helps to compensate possible horizontal tilts of the projector.
The keystone adjustment is not available for model HT280E
ttre
ne pas comprome d'incende
ATTENTIO N: pour contre les resque fusible de meme type
la protection remplacer mems par un caracteristi protection que against
et de CAUTION: fire, replace for continued
only risk of with same fuse. type
and rating
with 1080i input signal.
