- Page 1 HT3000 HOST manuale d’uso ed installazione user and installation manual manuel d’utilisation et d’installation bedienungs und wartungsanleit manual de uso e instalación manual de utilização ВИДЕОПРОЕКТОР 使用及安装手册 Downloaded From projector-manual.com Sim2 Manuals...
-
Page 2: Table Of Contents
USB port, an RS232 serial port or the RJ45 Ethernet port. The appliance has been subjected to exhaustive op- erating tests by SIM2 to guarantee the highest quality, The projector bulb life should thus initially be around 30-60 hours. In addition to the customary checks, the Quality Control department also runs additional statistical tests before shipment. -
Page 3: Safety Warnings
To prevent harmful materials from being released into the environment and to promote the use of natural materials, SIM2 Multimedia provides the following information regarding the disposal and re- cycling of the product. Waste electrical and electronic materials (WEE) should never be disposed of in normal urban waste disposal facilities. -
Page 4: Product Disposal
To prevent overheating, allow a free space of at least 40 cm at the back of the projector. Do not obstruct the ventila- tion slots. Do not place the unit near heat sources such as heaters, radiators or other devices (including amplifiers) that Downloaded From projector-manual.com Sim2 Manuals... -
Page 5: Contents Of The Packaging
Opens the Memory management menu. Selects lens zoom adjustment. INFO Displays information on the selected source FOCUS FOCUS and projector status. Sets the lens focus. FORMAT Selects the image Aspect ratio. AUTO Automatically optimises the projected image. Downloaded From projector-manual.com Sim2 Manuals... - Page 6 Selection menu. Led Red Please Note: The keys on the front panel of the HOST are “Touch Sensitive”. This means you do not need to press the keys but simply apply a light touch. Downloaded From projector-manual.com Sim2 Manuals...
-
Page 7: Connection Panel
We recommend using high quality serial or USB cables to ensure that the electrical control signals do not deteriorate (4,5) S-VIDEO and are therefore read correctly. A specific SIM2 driver must Television receiver, DVD player, VCR, Camcorder, video be installed on the control PC, supplied by your dealer/dis- game console tributor to use the USB port. -
Page 8: Installation
Take care that the cable is not too taught or that it can be POSITIONING THE 2 UNITS tugged: in addition to disconnecting the connectors, this The HT3000 HOST system is made up of two separate units may cause damage to them. (HOST and HT3000 projector), each of which have a power... -
Page 9: Network Functions
NETWORK FUNCTIONS (RJ45 connector) TYPE OF IP ADDRESS This screen permits you to select the type of IP address to The HT3000 HOST system has a 10/100 Mbit Ethernet in- be assigned: terface located on the HOST system connector panel to 1. - Page 10 Domain name, SMTP Mail Server: parameters to be en- tered according to the specific network settings to which the HT3000 HOST projector is connected. IMPORTANT: To save the network settings the projector needs to be rebooted, set the system to standby and wait for the cooling sequence to complete.
- Page 11 HOST in the two cases: the deinterlacing performed by the ATTENTION: When switching between inputs the im- HT3000 HOST is often more effective than that performed age is deliberately ‘frozen’ to allow time for the sys- by the sources themselves.
-
Page 12: On-Screen Menus
◀ ▶ keys. For others (e.g. CINEMA MODE) you can choose between two options offered on the same line and selectable using ◀ ▶ keys. Downloaded From projector-manual.com Sim2 Manuals... - Page 13 Downloaded From projector-manual.com Sim2 Manuals...
- Page 14 The image is projected in the centre of the AUTO Native User 1 screen and if its horizontal and/or vertical dimensions are User 2 = 0.009 smaller than the display, it is bordered by vertical and/or horizontal black bands. User Downloaded From projector-manual.com Sim2 Manuals...
- Page 15 There are 3 sets of gamma curves: Standard (ST), Enhanced A on the remote control. When this procedure is requested SIM2 (EN) and Graphics (GR). The Standard curve has been it is helpful to have a white or light coloured background in defined for general use, and is set for camcorders, digital the current picture on the screen.
- Page 16 If this adjustment is insufficient to centre the image on the screen, tilt the projector and use the Vertical keystone adjust- ment to compensate for the resulting distortion. Downloaded From projector-manual.com Sim2 Manuals...
- Page 17 Confirm? LAMP POWER If your projection room is especially dark, the images projected by the HT3000 HOST system may appear to be excessively bright. Use the LAMP POWER function to reduce the power used to operate the lamp while achieving maximum image quality.
- Page 18 MENU+ key on Determines the type of background for the On Screen Display the remote control. If you wish to cancel the changes, press (opaque or transparent). MENU- on the remote control. Downloaded From projector-manual.com Sim2 Manuals...
- Page 19 The system does not recognise any signal applied to the ▶ key. The settings stored in the memory you have selected selected input. In this case: will be applied to the projected image, while a message will Downloaded From projector-manual.com Sim2 Manuals...
-
Page 20: Cleaning And Maintenance
DVI-D input. • Make sure the video or graphic signals supplied by the source are compatible with the HT3000 HOST system’s technical specifications and, in particular, with those of the selected input. •... -
Page 21: Optional Accessories
Adjust the image width and height, selecting Aspect in the IMAGE /ASPECT menu. safety regulations provided with the bracket in the • Adjust the overscan setting applied to the image on the packaging. Downloaded From projector-manual.com Sim2 Manuals... -
Page 22: Technical Specifications
EN 55024 Outputs: 2 12V jack connectors (1 active when system EN 61000-3-2 powered, 1 active when 16:9 aspect ratio EN 61000-3-3 selected) Transport: IEC 68-2-31, IEC 68-2-32 Image shift range: +50% image -33% image Downloaded From projector-manual.com Sim2 Manuals... -
Page 23: Appendix
HT3000 HOST APPENDIX DIMENSIONS HT3000 HOST PROJECTION DISTANCES INSTALLATION INSTRUCTIONS Downloaded From projector-manual.com Sim2 Manuals... -
Page 24: App.1
HT3000 HOST APP.1 HOST DIMENSIONS (in brackets inches dimensions) 10 (0,39) 49,9 (1,92) 165 (6,5) 289 (11,37) 301 (11,85) APP.1 HT3000 HOST DIMENSIONS Downloaded From projector-manual.com Sim2 Manuals... - Page 25 16,56 22,44 21,79 30,4 -24,3 36,8 156,9 88,2 19,87 26,93 26,15 36,48 -29,1 44,1 191,7 107,9 24,29 32,92 31,96 44,58 -35,6 53,9 (*) H-screen center= H-screen center (*) H -screen center=H-lens center (in floor position) Downloaded From projector-manual.com Sim2 Manuals...
- Page 26 13,12 17,77 17,26 24,07 -19,4 29,4 165,6 70,5 15,74 21,33 20,71 28,89 -23,3 35,2 202,4 86,1 19,24 26,07 25,31 35,31 -28,4 43,1 (*) H-screen center= H-screen center (*) H -screen center=H-lens center (in floor position) Downloaded From projector-manual.com Sim2 Manuals...
-
Page 27: App.3 Installation Instructions (Vertical Shift)
App.3 INSTALLATION INSTRUCTIONS (VERTICAL SHIFT) To install the HT3000 HOST system correctly place the projector so that the projected image completely fills the screen. Ideally, to avoid image distortion, the projector should be positioned perfectly perpendicular to the projection screen, as shown in the figure below. - Page 28 The examples shown in the figure give only general indication on the use of the vertical shift. Each projection lens may require differing vertical shift settings. For more detailed information, see the technical specifications or contact an authorised SIM2 Multimedia centre. Downloaded From projector-manual.com Sim2 Manuals...
- Page 29 SIM2 Multimedia S.p.a. Viale Lino Zanussi, 11 33170 Pordenone - ITALY Phone +39,434,383,253-256 Fax +39.434.383260-261 www.sim2.com e-mail: info@sim2.it SIM2 USA Inc. 10108 USA Today Way 33025 Miramar FL - USA Phone +1.954.4422999 Fax +1.954.4422998 www.sim2usa.com e-mail: sales@sim2usa.com SIM2 Deutschland GmbH Arndtstrasse 34-36 - D-60325 Frankfurt Am Main Phone 0800.800.7462 (Germany only)
