4.2.1-1 Event Logs – Control Event Log – Event Log Filter
Alarms
22/59 Thermostat - Shows/hides thermostat alarm events.
23/59 Torque Trip OP - Shows/hides torque trip in the open
direction alarm events.
24/59 Torque Trip CL - Shows/hides torque trip in the closing
direction alarm events.
25/59 Int.Timer Active - Shows/hides Interrupter Timer
alarm events.
26/59 Motor Stall - Shows/hides motor stall alarm events.
27/59 Inhibit Time - Shows/hides inhibit time alarm events.
28/59 Monitor Relay - Shows/hides monitor relay alarm events.
29/59 PStroke Fail - Shows/hides partial stroke failure
alarm events.
30/59 ControlContention - Shows/hides control contention
alarm events.
31/59 Comms Loss - Shows/hides communications loss
alarm events.
32/59 Phase Loss - Shows/hides phase loss alarm events.
33/59 Mains Restart - Shows/hides mains restart alarm events.
34/59 Phase Rotation - Shows/hides phase rotation
alarm events.
Status
35/59 Moving Open - Shows/hides moving open status events.
36/59 Moving Closed - Shows/hides moving closed
status events.
37/59 Contactor CW - Shows/hides clockwise contactor
energised status events.
38/59 Contactor ACW - Shows/hides anti-clockwise contactor
energised status events.
39/59 Open Limit - Shows/hides actuator open limit
status events.
40/59 Closed Limit - Shows/hides actuator closed limit
status events.
41/59 Manual - Shows/hides manual engaged status events.
42/59 PStroke Active - Shows/hides partial stroke active
status events.
continued
Contacts (Checkbox indicates contact made)
43/59 S1 - Shows/hides contact S1 status.
44/59 S2 - Shows/hides contact S2 status.
45/59 S3 - Shows/hides contact S3 status.
46/59 S4 - Shows/hides contact S4 status.
47/59 S5 - Shows/hides contact S5 status.
48/59 S6 - Shows/hides contact S6 status.
49/59 S7 - Shows/hides contact S7 status.
50/59 S8 - Shows/hides contact S8 status.
51/59 S9 - Shows/hides contact S9 status.
52/59 S10 - Shows/hides contact S10 status.
53/59 S11 - Shows/hides contact S11 status.
54/59 S12 - Shows/hides contact S12 status.
Refer to PUB002-059 for information on the Remote
Hand Station.
IQ3 Full Configuration Manual – Section: Data Log
