Table of Contents

1. Introduction __________________________3
1.1 Using the Rotork Setting Tool ___________4
ACTUATOR
SETTING TOOL
1.2 Connecting to the actuator _____________6
1.3 Password Security _____________________7
2. Settings ______________________________8
2.1 Settings - Limits _______________________8
2.2 Settings - Indication __________________11
2.3 Settings - Control ___________________ 14
2.4 Settings - ESD ______________________ 32
2.5 Settings - Security ___________________ 34
2.6 Settings - Defaults ___________________ 35
3. Status ______________________________ 36
3.1 Status - Control _____________________ 36
3.2 Status - Alarms _____________________ 40
3.3 Status - Movement ___________________41
3.4 Status - Indication ___________________ 42
3.5 Status - Diagnostics __________________ 43
4. Data Log ___________________________ 44
4.1 Data Log - Torque Logs ______________ 45
4.2 Data Log - Event Logs ________________ 47
4.3 Data Log - Trend Logs ________________51
4.4 Data Log - Operation Logs ____________ 54
4.5 Data Log - Partial Stroke Logs _________ 58
4.6 Data Log - Set Log Date ______________ 59
5. Assets ______________________________ 60
5.1 Assets - Actuator ___________________ 61
5.2 Assets - Valve _______________________ 64
5.3 Assets - 2nd Stage Gear Box __________ 64
5.4 Assets - Service History ______________ 65
5.5 Assets - Service Alarms ______________ 65
5.6 Assets - NAMUR 107 ________________ 66
5.7 Assets - Online Help _________________ 67

1. Introduction

This manual provides instruction on the
setup and analysis of the actuator.
It is structured so that instruction on using the
Setting Tool, navigation and password security
is contained in Section 1. This must then be
applied when changing settings and viewing
information as set out in Sections 2 - 5.
The user must therefore be familiar with the
operations contained in Section 1 before
proceeding.
This manual should be read in conjunction with
PUB002-039 IQ Range Instructions for Safe Use,
Installation, Basic Setup and Maintenance and
PUB002-065 IQT Range Instructions for Safe
Use, Installation, Basic Setup and Maintenance
supplied with the actuator.
IQ3 Full Configuration Manual - Section: Introduction
3
