Examples - Sim2 DLP RS-232C Specifications

KEYSTONE
HORIZONTAL
LANGUAGE
OSD POSITION
HORIZONTAL
OSD POSITION
VERTICAL
INPUT 3
(COMP. RGB) /
SIGNAL TYPE

5. Examples

1. Send the simulated "SWITCH ON FROM STAND-BY AND SELECT SOURCE" Remote Control
keycode.
Remote Control allows Switching on from Stand-by via one of the keys "1", "2" ... "5".
Send, for instance, the code relative to key "1": BEEF02060080E5490100000000.
The projector switches on and selects Input 1.
The projector returns the response code: 06 (Acknowledged with no error).
NOTE: Commands that simulate keys "1", "2" ... "5" switch on the unit and select the corresponding
Source.
Command that simulate key 0 switches on the unit: the last source memorised prior to switch off is
automatically selected.
2. Send the simulated "MENU RIGHT" Remote Control keycode.
Send the packet: BEEF02060023E75A0100000000.
The OnScreen Display appers on the screen.
The projector returns the response code: 06 (Acknowledged with no error).
BE EF 03 19 00 6B 9F 03 1E 08 00 00 00 00 00 00
INCREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 05 35 04 1E 08 00 00 00 00 00 00
DECREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 15 35 01 05 24 00 00 00 00 00 00
SET ENGLISH
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 85 F4 01 05 24 00 00 00 00 00 00
SET ITALIANO
01 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 74 B4 01 05 24 00 00 00 00 00 00
SET FRANCAIS
02 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 E4 75 01 05 24 00 00 00 00 00 00
SET DEUTSCH
03 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 D6 37 01 05 24 00 00 00 00 00 00
SET ESPANOL
04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 46 F6 01 05 24 00 00 00 00 00 00
SET PORTUGUES
05 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 82 88 03 61 08 00 00 00 00 00 00
INCREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 EC 22 04 61 08 00 00 00 00 00 00
DECREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 7D 6C 03 62 08 00 00 00 00 00 00
INCREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 13 C6 04 62 08 00 00 00 00 00 00
DECREMENT
00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 92 04 01 82 08 00 00 00 00 00 00
SET YCrCb AutoSync
14 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 5B 0C 01 82 08 00 00 00 00 00 00
SET YCrCb 15kHz
08 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 51 06 01 82 08 00 00 00 00 00 00
SET YCrCb 32kHz
10 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 97 01 01 82 08 00 00 00 00 00 00
SET RGB AutoSync
18 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 5E 09 01 82 08 00 00 00 00 00 00
SET RGB 15kHz
04 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
BE EF 03 19 00 98 0E 01 82 08 00 00 00 00 00 00
SET RGB 32kHz
0C 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
9
SIM2 DOMINO 20H / DOMINO 30H
RS-232C CONTROL SPECIFICATIONS
