Summary of Contents for Sim2 DOMINO DTV S

  • Page 1 RSAG2. 025. 7895SS A Bar code here, for material number reference only. SIM2 MULTIMEDIA S.R.L.
  • Page 2 Instructions for Laser Projector Use (DTV S)
  • Page 3 Warm Tips Please carefully read the instructions before using the product and keep it properly. The company disclaims any responsibility for accidents caused by violating the safety precautions and instructions in this manual. Users are not allowed to open the casing without authorization because of high voltage in this product.
  • Page 4 Laser safety parameters of the whole device: Laser safety standard: Class I laser product, meeting the safety standard of GB 7247.1.2012 Radiation parameters:  Maximum output of laser radiation: ≤ 66mW  Emission wavelength: Blue ray: 459-471nm Green ray: 519-531nm Red ray: 635-651nm Class 1 laser product do not stare into beam.
  • Page 5 Symbol Descriptions This triangle pattern with lightning-shaped arrow is a Matters needing attention · warning symbol to remind you that the voltage inside the product is dangerous. This triangle pattern with exclamation mark is a Next step warning symbol to remind you of important instructions related to the product.
  • Page 6 Important Notes Please read the following carefully before using this product: 1. Safety Warnings In case of thunderstorm, please unplug the power plug and the network cable to avoid damage to the machine. This product uses the power plug as the power disconnecting device. The socket should be installed near the product for easy access and sundries cannot be stacked around the socket for the sake of convenient use.
  • Page 7  The machine should be placed in a flat and stable place, instead of somewhere prone to shaking.  Please do not place the machine in high-temperature places where there is direct sunlight or heating devices, places where water, oil and smoke can easily enter the machine, or places where there is much dust and is moist.
  • Page 8  Do not install the machine as shown in the figure below. Laser beam Confined space (only the light outlet outward) Insufficient ventilation space may cause this device to overheat or become damaged or even fired.
  • Page 9 3. Precautions for Use Please do not try to disassemble or repair any part of this device by yourself, which may cause damage to it and personal injury, and invalidate your product warranty. If this device gets dirty, please unplug its power plug and wipe it with a semi dried soft cloth dipped with a small amount of diluted neutral detergent, but do not wipe it repeatedly to avoid scratching.
  • Page 10 4. Laser Laser safety parameters of the whole device: Laser safety standard: Class I laser product, meeting the safety standard of GB 7247.1 Radiation parameters:  Maximum output of laser radiation: ≤ 66mW  Emission wavelength: Blue ray: 459-471nm Green ray: 519-531nm Red ray: 635-651nm Watching direction Screen...

  • Page 11: Table Of Contents

    Table of Contents Device Accessories ............................. 2 Feet Adjustment to Calibrate the Display Screen ....................3 Settings Adjustment ............................9 Remote Control ..............................10 Control Panel ..............................13 Introduction to Terminals ..........................15 Connection Description............................. 16 First Start ................................18 OSD menu .................................

  • Page 12: Device Accessories

    Device Accessories User Manual User Manual * 1 Remote control * 1 Power cord * 1...

  • Page 13: Feet Adjustment To Calibrate The Display Screen

    Feet Adjustment to Calibrate the Display Screen Front foot 2 Front foot 1 Back foot 2 Back foot 1 Fit the Image to the Screen [Note] Feet rotation of this device is described from an overlooking view. 2. If the image is narrower than 1.
  • Page 14 5. If the image shifts to the upper 6. If the image shifts to the lower side, rotate the feet of the side, rotate the feet of the projector clockwise. projector counterclockwise. Adjust Length of the Left and Right Side of the Image 2.
  • Page 15 Adjust Length of the Top and Bottom of the Image 1. If the image is longer at the top and 2. If the image is shorter at the top and longer shorter at the bottom, please rotate the back at the bottom, rotate the back foot 1 / back foot 1 / back foot 2 clockwise or rotate the foot 2 counterclockwise or rotate the front front foot 1 / front foot 2 counterclockwise.
  • Page 16 Typical Approaches to Geometric Distortion Adjustment  Adjust the Upper-left Corner of the Image The situation gets worse after raising left feet The bottom of the image is slightly Adjust the image bottom to the same length of the Raise left feet screen bottom (opening on the inner side of the...
  • Page 17  Adjust the Upper-right Corner of the Image The situation gets worse after raising right feet The bottom of the image is slightly upward Raise right feet Adjust the image bottom to the same length projector of the screen bottom (opening on the inner side of the frame) and parallel with the screen bottom 1.
  • Page 18 Display Size 100inch 110inch 120inch H(mm) D(mm) * Display size is the diagonal screen * Due to mechanical tolerances the above numbers could change of ±5%; please consider this while designing your installation. H: The “H” is the distance from the bottom of the DTV-S to the lower edge of the screen W: The “D”...

  • Page 19: Settings Adjustment

    Settings Adjustment Focus adjustment: Settings - Optical Machine - Focus, adjust it by pressing Up / Down buttons on the remote control. Keystone correction: Settings - Optical Machine - Keystone Correction, select a point for adjustment using Up / Down / Left / Right buttons.

  • Page 20: Remote Control

    Remote Control On / Off button Display Mode Screen Shot Media Signal Resource Settings OK/ENTER Return/Back Info Menu Mute Audio Settings Volume +/- Home Main Menu  Pairing Steps When using the remote control for the first time, press the Home Main Menu button to access the pairing interface, and then press any key other than Standby of the remote control to start pairing.
  • Page 21 remove what’s causing the interference and pair it again.  When pressing the remote control buttons, if the indicator light flashes red, it means that the remote control is not paired with the projector or the remote control is not paired successfully. Please press and hold the Menu button for 3 seconds to start pairing and the pairing succeeds...
  • Page 22 Screen shot Media Source selection Return Home main menu Audio Mute Power on/off Display mode Settings D-pad Info Menu Audio Settings Volume + and - Screen shot Capture and store on key pen inserted on a USB port the current image on the screen Media Recall the Media menu...

  • Page 23: Control Panel

    Control Panel Front view Left view Indicator light Right view Air vent Remote control receiver Air vent [Note]  There may be protective films on the surface of the upper shell and at the air vents. Please remove them before starting this device for the first time to avoid damage to it. Light-emitting lens Standby button Eye protection sensor...
  • Page 24 [Note]  As power failure and system processing take time, please do not switch on and off this device continuously and quickly, which may cause malfunction.  Arrow buttons may not work on some interfaces and in some applications when operating the homepage and using the Menu.

  • Page 25: Introduction To Terminals

    Introduction to Terminals Rear view USB 1 5V 0.5A Power input HDMI 1 HDMI 2 （ARC） Service USB 2 Optical 5V 0.5A [Note] Some external devices may be unable to connect to this device due to specific differences. If this happens, please use appropriate signal wire or add adapters matching the ports.

  • Page 26: Connection Description

    Connection Description  Select Signal Input Press the Signal Resource button on the remote control to access the Signal Resource menu, and select the signal resource corresponding to the local port in the Signal Resource menu.  Connect to AV Devices Connect with HDMI Cable Set-top box / Player / Computer / DVD HDMI output...
  • Page 27 [Note] If you want to use the ARC function, the audio receiving device connected to the HDMI (ARC) port of the projector also needs to support the ARC function.  Connect to the Network Press the Settings button on the remote control to access the settings interface, select the Network, and press the button to access the Network menu Wireless Network Connection...

  • Page 28: First Start

    First Start 1 Power on / off  Connect the power cord of this device to a 220 V AC power socket.  Press the Standby button on the remote control to turn on this device, and then follow the navigation prompts after booting to complete settings (the navigation information after booting is subject to the actual situation).

  • Page 29: Osd Menu

    OSD Menu...
  • Page 31 Image...
  • Page 32 Image – Advanced settings...
  • Page 33 Light source...
  • Page 34 Audio...

  • Page 35: Miscellaneous

    Miscellaneous 1 Statement on Environmental Protection  This product meets the environmental protection requirements as prescribed in Administrative Measures for Limiting the Use of Hazardous Substances in Electrical and Electronic Products.  Within the environmental protection use period, there will be no leakage of hazardous substances, precipitation or other problems affecting consumers’...
  • Page 36 This table is prepared in accordance with SJ / T 11364. O: Indicate that the content of hazardous substances in all homogeneous materials of the part is below the limit prescribed in GB / T 26572. X: Indicate that the content of hazardous substances in at least one homogeneous material of the part exceeds the limit prescribed in GB / T 26572.
  • Page 37 [Statement]  Pictures and notes in the instructions are for reference only and they may be different from real products. Specific products in kind prevail. (This statement applies to the entire instructions)  Service and quality upgrade, and changes to product design and specifications will not be notified separately.

  • Page 38: Specifications

    Specifications Model DTV S Digital Light Processing (DLP 0.47), 1-chip Projection Type DLP Type: 4K, 3840 x 2160 Trichromatic RGB laser system Light source (expected lifetime approx. 25.000 hours, watching over 10000 films/2 hours per film) Focus Motorized - digital adjustments Dedicated menu for adjust 8 points (H, V): Geometry adjustments Keystone, Parallelogram, Pincushion...

  • Page 39: Ceiling Installation

    Inputs/outputs HDMI1/HDMI2 2.0, high speed interface 2x inputs HDMI HDMI1 support the ARC return 4K UHD@60Hz / 1080p@120Hz Optical fiber Audio output ARC return from HDMI1 RJ45 Ethernet Internet access and Sw update 2.4G/5G 802.11c WiFi Internet access and Sw update Hard disk or Flash drive USB 2.0 Audio/Video contents...
  • Page 40 Dimensions...
  • Page 42 Video formats available are shown below: Video Decoding Frame Encapsulation Audio Decoding Resolution Bit Rate Type Rate (Max) (Max) (Max) Dolby Audio, .avi Xvid 1920x1080 40Mbps 60fps MPEG1 (Layer 1, 2, 3) Dolby Audio, .avi .mpg .ts MPEG 2 1920x1080 80Mbps 60fps MPEG1 (Layer 1,...

  • Page 43: Appendices

    Appendices Regulation & Safety Notices This appendix lists the general notices of your projector. Notice: Shielded cables All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations Caution Changes or modifications not expressly approved by the manufacturer could void the user’s authority, which is granted by the Federal Communications Commission, to operate this projector.
  • Page 44 Trademarks • DLP is trademark or registered trademark of Texas Instruments. • HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. • Other product and company names mentioned in this user’s manual may be the trademarks or registered trademarks of their respective holders.
  • Page 45 SIM2 USA SIM2 USA Inc. 10216 NW 47th Street Sunrise, FL 33351 Phone: +1 (954) 442 2999 Email: sales@sim2usa.com www.sim2usa.com SIM2 BRIONVEGA Co., Ltd Room 303-304, No. 244 Liaoning Road Shanghai 200080 – CN Phone/Fax: 86-21-62881991 Email: InfoCHINA@sim2.com (EN/1.8)
