D35
DLP™ VIDEO
PROJECTOR
RS-232C
CONTROL

SPECIFICATIONS

Document Revision 1.0 (16 June 2006)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D35 and is the answer not in the manual?

Questions and answers

Related Manuals for Sim2 D35

Summary of Contents for Sim2 D35

  • Page 1: Specifications

    DLP™ VIDEO PROJECTOR RS-232C CONTROL SPECIFICATIONS Document Revision 1.0 (16 June 2006)

  • Page 2: Table Of Contents

    2. CONNECTION 3. COMMUNICATION PROTOCOL EADER AYLOAD 4. COMMANDS EMOTE ONTROL EYCODES PERATION ODES 5. EXAMPLES 6. WARNINGS Revision History: Revision Date 20 April 2004 Software Version 2.48.55 F or higher SIM2 D35 RS-232C CONTROL SPECIFICATIONS Description of Change Initial version.

  • Page 3: Introduction

    1. Introduction This document describes the communication and data formats used to control SIM2 D35 projector via RS- 232C port. 2. Connection Switch off your Personal Computer and Projector before connecting RS 232C cable. Use a standard serial cable with 9 pin female to the Personal Computer and 9 pin male to the Projector: pin 2 connects to pin2, pin 3 to pin 3 and pin 5 to pin 5.

  • Page 4: Communication Protocol

    The entire packet size is variable, being the sum of the fixed-size packet header and variable-sized packet payload: Event packet size is 13 bytes and Operation packet size is 32 bytes. Each packet received by the projector is acknowledged with a return code: : Acknowledged with no error : Acknowledged, but an error has occurred.

  • Page 5: Commands

    4. Commands Remote Control Keycodes The following commands send simulated Remote Control input to SIM2 D35 projector. Remote Control Keycodes: STAND BY CURSOR UP CURSOR LEFT CURSOR RIGHT CURSOR DOWN MENU LEFT MENU RIGHT FREEZE ZOOM FOCUS INFO AUTO ASPECT NORMAL...

  • Page 6: Direct Access Codes

    When the unit is in Stand-by state, this command switches on the unit and the last source memorised prior to switch off is automatically selected. When the unit is in Stand-by state, this command switches on the unit and selects the corresponding Source. RS-232C CONTROL SPECIFICATIONS SIM2 D35...

  • Page 7: Operation Codes

    Operation Codes The following codes provide direct access to SIM2 D35 User Interface operations not accessible via a single Remote Control command. Operation Codes: Operation Action INCREMENT BRIGHTNESS DECREMENT INCREMENT CONTRAST DECREMENT INCREMENT COLOR DECREMENT INCREMENT TINT DECREMENT INCREMENT SHARPNESS (Video)
  • Page 8 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 BE EF 03 19 00 13 C6 04 62 08 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 SIM2 D35 RS-232C CONTROL SPECIFICATIONS...

  • Page 9: Signal Type

    BEEF02060062E44B0100000000 6. Warnings When the number of bytes sent to the Projector is greater than indicated for the Command (32 bytes for Operation Packets and 13 bytes for Event Packets), excess data will be ignored. Conversely, if number of bytes sent to the Projector is smaller than required by the Communication Protocol, an Error Code will be returned.
