Page 1: Specifications
DOMINO 20H DOMINO 30H DLP™ VIDEO PROJECTOR RS-232C CONTROL SPECIFICATIONS Document Revision 1.1 (20 July 2004) -
Page 2: Table Of Contents
Table of Contents 1. INTRODUCTION 2. CONNECTION 3. COMMUNICATION PROTOCOL EADER AYLOAD 4. COMMANDS EMOTE ONTROL EYCODES PERATION ODES 5. EXAMPLES 6. WARNINGS Revision History: Revision Date 20 July 2004 20 April 2004 Software Version 2.36.09 F or higher 2.33.00 F or higher SIM2 DOMINO 20H / DOMINO 30H RS-232C CONTROL SPECIFICATIONS Description of Change... -
Page 3: Introduction
Switch off your Personal Computer and Projector before connecting RS 232C cable. Use a standard serial cable with 9 pin female to the Personal Computer and 9 pin male to the Projector: pin 2 connects to pin2, pin 3 to pin 3 and pin 5 to pin 5. -
Page 4: Communication Protocol
The entire packet size is variable, being the sum of the fixed-size packet header and variable-sized packet payload: Event packet size is 13 bytes and Operation packet size is 32 bytes. Each packet received by the projector is acknowledged with a return code: : Acknowledged with no error : Acknowledged, but an error has occurred. -
Page 5: Commands
4. Commands Remote Control Keycodes The following commands send simulated Remote Control input to SIM2 DOMINO 20H / DOMINO 30H projectors. Remote Control Keycodes: STAND BY CURSOR UP CURSOR LEFT CURSOR RIGHT CURSOR DOWN MENU LEFT MENU RIGHT FREEZE ZOOM FOCUS INFO AUTO... -
Page 6: Direct Access Codes
Direct access codes Goto Brightness BE EF 02 06 00 C7 E1 7E 01 00 00 00 00 Goto Contrast BE EF 02 06 00 16 E0 7F 01 00 00 00 00 Goto Color BE EF 02 06 00 19 F4 80 01 00 00 00 00 Goto Tint BE EF 02 06 00 C8 F5 81 01 00 00 00 00 When the unit is in Stand-by state, this command switches on the unit and the last source... -
Page 7: Operation Codes
Operation Codes The following codes provide direct access to SIM2 DOMINO 20H / DOMINO 30H User Interface operations not accessible via a single Remote Control command. Operation Codes: Operation Action INCREMENT BRIGHTNESS DECREMENT INCREMENT CONTRAST DECREMENT INCREMENT COLOR DECREMENT INCREMENT TINT DECREMENT INCREMENT... - Page 8 INCREMENT COLOR TEMP USER/ GAIN RED DECREMENT INCREMENT COLOR TEMP USER/ GAIN GREEN DECREMENT INCREMENT COLOR TEMP USER/ GAIN BLUE DECREMENT INCREMENT COLOR TEMP USER/ OFFSET RED DECREMENT INCREMENT COLOR TEMP USER/ OFFSET GREEN DECREMENT INCREMENT COLOR TEMP USER/ OFFSET BLUE DECREMENT SET FILM GAMMA...
-
Page 9: Examples
Send, for instance, the code relative to key "1": BEEF02060080E5490100000000. The projector switches on and selects Input 1. The projector returns the response code: 06 (Acknowledged with no error). NOTE: Commands that simulate keys "1", "2" ... "5" switch on the unit and select the corresponding Source. -
Page 10: Warnings
BEEF02060062E44B0100000000 6. Warnings When the number of bytes sent to the Projector is greater than indicated for the Command (32 bytes for Operation Packets and 13 bytes for Event Packets), excess data will be ignored. Conversely, if number of bytes sent to the Projector is smaller than required by the Communication Protocol, an Error Code will be returned.
