4. Commands

Remote Control Keycodes

The following commands send simulated Remote Control input to SIM2 DOMINO 20H / DOMINO 30H
projectors.
Remote Control Keycodes:
Key
STAND BY
(1)
0
(2)
1
(2)
2
(2)
3
(2)
4
(2)
5
6
7
8
9
ESC
CURSOR UP
CURSOR LEFT
CURSOR RIGHT
CURSOR DOWN
MENU LEFT
MENU RIGHT
FREEZE
ZOOM
FOCUS
INFO
AUTO
ASPECT NORMAL
ASPECT ANAMORPHIC
ASPECT LETTERBOX
ASPECT PANORAMIC
ASPECT PIXEL TO PIXEL
ASPECT USER 1
ASPECT USER 2
ASPECT USER 3
VCR
Command
BE EF 02 06 00 51 E4 48 01 00 00 00 00
BE EF 02 06 00 6B E6 52 01 00 00 00 00
BE EF 02 06 00 80 E5 49 01 00 00 00 00
BE EF 02 06 00 B3 E5 4A 01 00 00 00 00
BE EF 02 06 00 62 E4 4B 01 00 00 00 00
BE EF 02 06 00 D5 E5 4C 01 00 00 00 00
BE EF 02 06 00 04 E4 4D 01 00 00 00 00
BE EF 02 06 00 37 E4 4E 01 00 00 00 00
BE EF 02 06 00 E6 E5 4F 01 00 00 00 00
BE EF 02 06 00 89 E7 50 01 00 00 00 00
BE EF 02 06 00 58 E6 51 01 00 00 00 00
BE EF 02 06 00 0D E6 54 01 00 00 00 00
BE EF 02 06 00 DC E7 55 01 00 00 00 00
BE EF 02 06 00 EF E7 56 01 00 00 00 00
BE EF 02 06 00 3E E6 57 01 00 00 00 00
BE EF 02 06 00 C1 E6 58 01 00 00 00 00
(-)
BE EF 02 06 00 10 E7 59 01 00 00 00 00
(+)
BE EF 02 06 00 23 E7 5A 01 00 00 00 00
BE EF 02 06 00 F2 E6 5B 01 00 00 00 00
BE EF 02 06 00 94 E6 5D 01 00 00 00 00
BE EF 02 06 00 76 E7 5F 01 00 00 00 00
BE EF 02 06 00 A7 E6 5E 01 00 00 00 00
BE EF 02 06 00 79 E2 60 01 00 00 00 00
BE EF 02 06 00 2A F4 83 01 00 00 00 00
BE EF 02 06 00 9D F5 84 01 00 00 00 00
BE EF 02 06 00 4C F4 85 01 00 00 00 00
BE EF 02 06 00 7F F4 86 01 00 00 00 00
BE EF 02 06 00 AE F5 87 01 00 00 00 00
BE EF 02 06 00 51 F5 88 01 00 00 00 00
BE EF 02 06 00 80 F4 89 01 00 00 00 00
BE EF 02 06 00 B3 F4 8A 01 00 00 00 00
BE EF 02 06 00 9B E3 62 01 00 00 00 00
