Page 2
- X8: 7mm tap depth • Use provided hardware with accessories and hand tighten as needed. • Do not attempt to disassemble actuator, this will void the warranty and can cause permanent damage. For more information please visit: docs.hebi.us X-Series Hexapod Assembly Instructions...
Page 3
12 x A-2039-02 A-2038-02 A-2090-01 A-2091-01 A-2070-01R A-2070-01L A-2094-01L A-2094-01R A-2095-01 A-2095-01 12 x PP-2200-01 PP-2200-02 -2127-60-15 -2057-01 -2083-01 150mm Tube (Gas Spring – 15lbs.) 300mm Tube A-2050-01 Slip Ring Assembly *if necessary* fasteners included, not shown X-Series Hexapod Assembly Instructions...
Page 4
20 x 12 x A-2046-12 A-2046-18 A-2046-24 Power Cable, 12” Length Power Cable, 18” Length Power Cable, 24” Length 12 x PP-2061-01 PP-2059-01 PP-2060-01 Ethernet Cable, 36” Length Ethernet Cable, 12” Length Ethernet Cable, 24” Length X-Series Hexapod Assembly Instructions...
Page 5
Table of Contents Assembly Image Pages Chassis [6-8] Left Legs [9-16] Right Legs [17-24] Final [25-30] (includes wiring) X-Series Hexapod Assembly Instructions...
Page 9
Left Legs X-Series Hexapod Assembly Instructions...
Page 10
Align with actuator output hub tick mark (inside face parallel with tick mark and spring mounting hole going forward) X8-9 A-2070-01L X-Series Hexapod Assembly Instructions...
Page 17
Right Legs X-Series Hexapod Assembly Instructions...
Page 18
Align with actuator X8-9 output hub tick mark A-2070-01R (inside face parallel with tick mark and spring mounting hole going forward) X-Series Hexapod Assembly Instructions...
Wires that come from the daisy-chain power connections. previous joint should be inserted These fit well within the tubes between actuators. directly to actuator ports. Wires that connect to the next joint should be threaded through the actuator’s bore hole. X-Series Hexapod Assembly Instructions...
