- Page 1 FLAMA USER’S AND INSTALLER’S MANUAL v2.1 REV. 10/2018...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW This product is certified in accordance with European Community (EC) safety standards. 02. OPERATOR COMPONENTS TECHNICAL CHARACTERISTICS This product complies with Directive 2011/65/EU of the European 03. -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW STANDARDS TO FOLLOW • It is important for your safety that these instructions are followed. level or other level of access, , should be followed the minimum safety and • Keep these instructions in a safe place for future reference. health requirements for the use of work equipment workers at work in Directive •... -
Page 4: Operator
02. OPERATOR COMPONENTS 1 • Safe profile 2 • Motor 3 • Guide 4 • Maneuvers board 5 • Flashing light 6 • Pressure button 7 • Informative LEDS 8 • Runner profile (not included in kit) 9 • Tarpaulin 10 •... -
Page 5: Technical Characteristics 4A
10 RPM not happen. • Noise LpA < 60 dB (A) • Use appropriate screws to the place where the components of the FLAMA will be fixed. • Force 120 Nm • Working temperature It is very important that all precautions are respected! -25°C to 55°C... -
Page 6: Dimensions
03. PRE-INSTALLATION DIMENSIONS ∫ INSTALLATION OUTSIDE THE PASSAGE SPAN ∫ INSTALLATION INSIDE THE PASSAGE SPAN 254mm 30mm 30mm 250mm 85mm 85mm 120mm 120mm GUIDE GUIDE PASSAGE SPAN PASSAGE SPAN WALL WALL ∫ MANEUVER BOARD 40mm If the installation is made inside the vain, the passing area reduces 300mm in height and 170mm in width. -
Page 7: Installation
SCREWS taking into account the installation location. It is also important that the installation site is properly leveled, since only then will it be possible to ensure the correct operation of the FLAMA. PASSAGE SPAN PASSAGE SPAN GUIDE 01 •... -
Page 8: Settings
05. SETTINGS CONTROL BOARD DIAGRAM DIP SWITCH 1 MOTOR WIRES DOOR OPERATING MODE 01 • red wire ON • the door operates in automatic to open 02 • black wire and operates manually to close. 03 • yellow wire OFF • the door operates in automatic to open 04 •... -
Page 9: Limit Switches Programming 8A
05. SETTINGS 05. SETTINGS LIMIT SWITCHES PROGRAMMING LIMIT SWITCHES PROGRAMMING WITH INTERMEDIATE STOP 1 2 3 4 5 LED1 Status 3 4 5 LED-6 If the door is operating in the wrong direction, change on dip 4. 3 4 5 LED1 Status Stop... -
Page 10: Auxiliary Information
05. SETTINGS 06. AUXILIARY INFORMATION LIMIT SWITCHES PROGRAMMING WITH INTERMEDIATE STOP MANUAL OPERATING MODE It is possible to use the fire door in manual mode. To do this, access the inside of the maneuvers board and slide the door operation switch (page 7A). From that moment, it will be possible to open and close the door using the up and down buttons.
