- Page 1 FLAMA FLAMA USER’S AND INSTALLER’S MANUAL v7.2 REV. 07/2022...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX ATTENTION: 01. SAFETY INSTRUCTIONS This product is certified in accordance with European 02. PACKAGE Community (EC) safety standards. INSIDE PACKAGE This product complies with Directive 2011/65/EU of the 03. OPERATOR European Parliament and of the Council, of 8 June 2011, on TECHNICAL CHARACTERISTICS the restriction of the use of certain hazardous substances PERFORMANCE DESIGNATION... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. Read all instructions carefully before beginning the installation/ WARNINGS FOR TECHNICIANS usage procedures and keep this manual in a safe place that it can be consulted whenever necessary. - Page 4 01. SAFETY INSTRUCTIONS RESPONSABILITY September 2009. • Attach the permanent label for the manual release as close as possible • Supplier disclaims any liability if: to the release mechanism. • Product failure or deformation result from improper installation • Disconnect means, such as a switch or circuit breaker on the electrical use or maintenance! panel, must be provided on the product’s fixed power supply leads in •...
-
Page 5: Package
02. PACKAGE 03. OPERATOR INSIDE PACKAGE TECHNICAL CHARACTERISTICS FLAMA is a fire curtain built with indicated galvanized steel profiles, with lacquer. The kit consists of the following components: • 01 Motor • 02 Side guides MANEUVER BOARD • 01 Iron Safe •... -
Page 6: Performance Designation 5A
03. OPERATOR 03. OPERATOR TECHNICAL CHARACTERISTICS SAFE PROFILE INSTALLATION MEASURES FLAMA has two models, and the installation of each model is variable due to its measurements. See the table below: STRUCTURE COFRE • Galvanized steel DX51D +Z Width Height 1000... -
Page 7: Dimensions
04. INSTALLATION FLAMA ST DIMENSIONS FLAMA XL DIMENSIONS ∫ MANEUVER BOARD DC95 ∫ MANEUVER BOARD DC120 AND DC160 40mm 40mm 400mm 320mm 300mm 140mm 260mm 130mm ∫ OUT OF PASSAGE SPAN ∫ OUT OF PASSAGE SPAN 105mm (MSL) 250mm 105mm... -
Page 8: Installation Map
04. INSTALLATION INSTALLATION MAP 1 • Safe profile 2 • Motor 3 • Guide 4 • Maneuvers board 5 • Flashing light 6 • RESET button 7 • Informative LEDS 8 • Runner profile (not included in kit) 9 • Fire Breaker Fabric 10 •... -
Page 9: Pre-Installation Information 8A
• Evaluate the security devices to be installed. This will ensure that unexpected accidents do not happen. • Use appropriate screws to the place where the components of the FLAMA will be fixed. • Do not use plastic wall plugs in the FLAMA installation. -
Page 10: Fixing The Side Guides And Maneuver Board
04. INSTALLATION FIXING THE SIDE GUIDES AND MANEUVER BOARD POSITION GUIDES Place the guides by inserting them through the openings at the bottom of the safe. FIX GUIDES With the guides against the wall mark the fixing points and then drill the holes. -
Page 11: Dc95 Control Board Diagram
3 4 5 Stop Down Setting Reset 10 11 12 13 14 15 16 17 18 19 20 21 22 23... -
Page 12: Dc120 And Dc160 Control Board Diagram
3 4 5 Stop Down Setting Reset 10 11 12 13 BLACK... -
Page 13: Limit Switches Programming
3 4 5 3 4 5 Stop Down Setting Reset 3 4 5 3 4 5 Stop Down Setting Reset 10 11 12 13 14 15 16 17 18 19 20 21 22 23 Down Setting Reset 10 11 12 13 14 15 16 17 18 19 20 21 22 23... - Page 14 3 4 5 Stop Down Setting Reset 10 11 12 13 14 15 16 17 18 19 20 21 22 23...
