ECO PLUS RAPID ROLL-UP DOOR
USER'S AND INSTALLER'S MANUAL
v3.1
REV. 02/2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECO PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Motorline professional ECO PLUS

Summary of Contents for Motorline professional ECO PLUS

  • Page 1 ECO PLUS RAPID ROLL-UP DOOR USER’S AND INSTALLER’S MANUAL v3.1 REV. 02/2024...

  • Page 2: Table Of Contents

    00. CONTENT 01. SAFETY INSTRUCTIONS INDEX This product is certified in accordance with European Community (EC) safety standards. 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW This product complies with Directive 2011/65/EU of the European 02. PACKAGE Parliament and of the Council, of 8 June 2011, on the restriction INSIDE PACKAGE of the use of certain hazardous substances in electrical and electronic equipment and with Delegated Directive (EU) 2015/863...
  • Page 3 01. SAFETY INSTRUCTIONS GENERAL WARNINGS • Children shouldn’t play with the product or opening devices to avoid the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. • If the power cable is damaged, it must be replaced by the Read all instructions carefully before beginning the installation/ manufacturer, after-sales service or similarly qualified personnel usage procedures and keep this manual in a safe place that it can...
  • Page 4 01. SAFETY INSTRUCTIONS the power supply cable. Please note that all the cables must enter conditions have been met. the control board from the bottom. • In the event of tripping of circuits breakers of fuse failure, locate • If the automatism is to be installed at a height of more than 2,5m the malfunction and solve it before resetting the circuit breaker or from the ground or other level of access, the minimum safety and replacing the fuse.

  • Page 5: Package

    TECHNICAL SPECIFICATIONS of the motor (see image). The ECO PLUS rapid door is built with its own white lacquered aluminum profiles and is suitable for • Turning to the right will open the door and areas with low air pressure, as it has 3 to 4 reinforcement bars.

  • Page 6: Dimensions - Normal Kit 5A

    03. AUTOMATISM 03. AUTOMATISM DIMENSIONS - NORMAL KIT DIMENSIONS - TUNNEL KIT 175 (OLC) 340 (OLM) 430 (PM) 500(PM) LVT - 300 Wall Wall LEGEND OLM • Motors side clearance OLC • Opposite side clearance PM • Minimum Lintel LVP • Passage Width LVT •...

  • Page 7: Installation

    04. INSTALLATION INSTALLATION MAP 1 • 7 • 13 • Aluminium safe profile Motor Photocell fixation plate 2 • 8 • 14 • Lateral Guides Connector Connections Photocell 3 • 9 • 15 • Motor cover Motor unlock lever Photocell columns 4 •...

  • Page 8: Safe Profile Fixation

    04. INSTALLATION SAFE PROFILE FIXATION Check the height of the lateral guides in order to POSITIONING TOP SAFE respect the measures required for installation. Apply the safe profile to the wall of the installation location, paying attention to horizontal leveling and the lintel Use the corresponding The safe profile should be centered with the passageway.

  • Page 9: Lateral Guides And Control Board Fixation

    04. INSTALLATION LATERAL GUIDES AND CONTROL BOARD FIXATION APPLY LATERAL GUIDES FIX LATERAL GUIDES TO THE GROUND Place the lateral guides by placing them on the inside of Start by drilling holes in the floor taking into the support plates and leaning against the wall. account the holes already in the plates for the The tarpaulin must be inside the lateral guides so that it application of the screws.

  • Page 10: Safe Profile Fixation - Tunnel Kit

    04. INSTALLATION SAFE PROFILE FIXATION - TUNNEL KIT Safe profile completely leaning against the wall and ceiling. POSITION TOP SAFE Insert the safe profile into the tunnel and apply at the desired location for installation, taking into account the horizontal leveling. Based on the holes in the support plates, mark the locations for drilling.

  • Page 11: Lateral Guides And Control Board Fixation - Tunnel Kit

    04. INSTALLATION LATERAL GUIDES AND CONTROL BOARD FIXATION - TUNNEL KIT APPLY LATERAL GUIDES FIX LATERAL GUIDES TO THE GROUND Place the lateral guides by placing them on the inside Start by drilling holes in the floor taking into of the support plates and leaning against the wall. The account the holes already in the plates for the tarpaulin must be inside the lateral guides so that it can application of the screws.

  • Page 12: Limit-Switches

    05. LIMIT-SWITCHES LIMIT-SWITCHES ADJUSTMENT • ADJUSTMENT • CONNECTIONS The ring 4 should activate the micro switch from below, and the ring 3 should activate the micro switch from above, as shown in the image below. Manually place the door in the area you want for the opening slowdown. Turn the adjusting screw 4 until the limit switch ring 4 activates the corresponding microswitch.

  • Page 13: Maintenance

    06. MAINTENANCE MAINTENANCE TASKS AND FREQUENCY During maintenance/revision check the parameters mentioned below. On the date you carry out the maintenance, mark with an "X" the tasks performed. Frequency Date Date Date Date Date Date Date (months) 12 24 36 1.

  • Page 14: Eu Declaration Of Conformity

    This declaration is invalid if occurs any alteration in the product without our agreement. Brand: Motorline Professional Model: ECO PLUS As such, the product meets with the following European directives: D D i i r r e e c c t t i i v v e e...
