  • Page 1 ECO FAST DOOR USER’S AND INSTALLER’S MANUAL v3.1 REV. 06/2018...
  • Page 2 00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW ATTENTION: 01. SAFETY INSTRUTIONS STANDARDS TO FOLLOW 02. THE PACKAGE This product is certified in accordance with European Community INSIDE THE PACKAGE (EC) safety standards. 03. THE AUTOMATISM TECHNICAL SPECIFICATIONS This product complies with Directive 2011/65/EU of the European 04.
  • Page 3 01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS STANDARDS TO FOLLOW STANDARDS TO FOLLOW • It is important for your safety that these instructions are followed. level or other level of access, , should be followed the minimum safety and • Keep these instructions in a safe place for future reference. health requirements for the use of work equipment workers at work in Directive •...
  • Page 4 02. PACKAGE 03. AUTOMATISM INSIDE PACKAGE TECHNICAL SPECIFICATIONS Inside the package you will find the following components: Eco fast doors are built in special aluminum profiles with white power coutting finish and suitable for areas with low wind pressure. With 3 reinforcement bars. •...
  • Page 5 04. INSTALLATION CARACTERÍSTICAS TÉCNICAS PRE-INSTALLATION INFO For a proper ECO FAST DOOR function, check the following parameters before installing the auto- matismo: • Read all steps at least once in order to get familiar with the installation and configuration process.
  • Page 6 04. INSTALLATION 04. INSTALLATION SAFE PROFILE FIXATION SAFE PROFILE FIXATION (FREE DOOR SPACE) (Vão de Obra) 1• Apply the safe aluminum profile in the wall’s installation location as shown in (A), taking 2 • Make holes at the marked locations, and then apply the safe profile on the wall and into account the horizontal position and the measures indicated in (B).
  • Page 7 04. INSTALLATION 04. INSTALLATION LATERAL GUIDES FIXATION LATERAL GUIDES FIXATION 4 • Attach the lateral guides on the support plates with screw, tightening them in the nuts located on the guides. 3 • Unlock the motor pulling the lever down (see page 06.A 5 •...
  • Page 8 04. INSTALLATION 04. INSTALLATION CONTROL BOARD FIXATION LIMIT-SWICHES ADJUSTMENT EXPANSION BOLTS BUCHAS SCREWS PARAFUSOS NOTE • The red ring must activate it’s micro-switch by the bottom and the white ring must do it by the top, as shown in the picture to the left. Microswitch connections: open white...
  • Page 9 04. INSTALLATION INSTALLATION MAP LEGEND: 01 • Aluminum safe profile 08 • Tarpaulin 02 • Safe profile’s support plate 09 • Control board 03 • Motor 10 • Guides fixing metal plates to ground 04 • Lateral guides 11 • Conection Plug 05 •...
