  • Page 1 CDPS-4H4HFS 4 by 4 HDMI 4Kx2K Matrix Operation Manual Operation Manual...
  • Page 3 DISCLAIMERS The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
  • Page 5: Table Of Contents

    CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........5 6.3 OSD Menu .........5 6.4 Remote Control ......11 6.5 RS-232 Protocols ......13 6.6 RS-232 Commands ......14...
  • Page 6: Introduction

    1. INTRODUCTION The 4 by 4 HDMI matrix which allows HDMI signal from any of its four sources to be routed to and displayed on any of its four connected HDMI displays simultaneously. With fast switching technology the device can greatly eliminate the time required by swapping or turning ON/OFF the connected displays.
  • Page 7: Features

    5. FEATURES • HDMI with 3D & 4Kx2K supported, HDCP and DVI compliant • Supports four HDMI inputs and four HDMI outputs • Displays any of four High-Definition sources on four HDTV displays simultaneously with fast switch • 3DTV Pass-Through •...
  • Page 8: Operation Controls And Functions

    6. OPERATION CONTROLS AND FUNCTIONS 6.1 Front Panel 1113 OUT A OUT B OUT C OUT D CANCEL MENU LOCK POWER 4K UHD 4X4 HDMI MATRIX FAST SWITCH CDPS-U4H4HFS IN 1 IN 2 IN 3 IN 4 TAKE ENTER PRESET MODE 7 9 1012 POWER: Press this button to turn ON the device and the LED will...
  • Page 9: Rear Panel

    6.2 Rear Panel HDMI IN HDMI OUT SERVICE CONTROL RS232 IR IN DC 19V HDMI IN: Connect from source equipments such as Blu-ray/DVD/ PS3 players, Set-Top-Box or any HDMI equipped source device for input signal sending. HDMI OUT: Connect to HDMI TV/display or HD Amplifier for output image and or audio display.
  • Page 10: Osd Menu

    6.3 OSD Menu Main Menu Sub Menu Description Default EDID Mode All Input port is using same EDID. In menu “EDID All”, can select suitable EDID. Appoint Each Input port can select individual EDID. In menu “EDID IN1~4” select suitable EDID. Exit...
  • Page 11 EDID All Sink A Copy Output A 8/2D/ display EDID PCM/1080p Sink B Copy Output B display EDID Sink C Copy Output C display EDID Sink D Copy Output D display EDID 8/2D/ Standard EDID, PCM/720p Content: deep color/2D3D/audio/ native resolution 8/2D/PCM/ Standard EDID, AC3/720p...
  • Page 12 EDID IN1 Same EDID All Select Input 1’s Same EDID EDID EDID IN2 Same EDID All Select Input 2’s Same EDID EDID EDID IN3 Same EDID All Select Input 3’s Same EDID EDID EDID IN4 Same EDID All Select Input 4’s Same EDID EDID Matrix Preset...
  • Page 13 Network Setup IP Mode DHCP , Static Static Setup Static IP 192.168.5.83 Mask Setup Static 255.255.255.0 Netmask Gate Setup Static 192.168.5.254 Gateway Do Re-Link Re-Link. After setup Network, the system need to re- link Exit Network Status Link Network status DHCP,Static or Not Linked Get IP...
  • Page 14 Sink A Info Type, Manuf. Detect and Analysis Output A display’s EDID Content: type(HDMI/ DVI/VGA), Manufactory/ Model number Native Content: native resolution Video Format Content: deep color, 2D or 3D, 4K2K Audio Format Content:PCM, BitStream, HBR Exit Sink B Info Same Sink A Detect and Info...
  • Page 15: Remote Control

    6.4 Remote Control POWER: Press this button to switch the system ON/OFF. OUT A IN 1 OUT A/D: Press these buttons onc OUT B TAKE IN 2 a time along with an IN buttons to select an input source for an output OUT C CANCEL IN 3...
  • Page 16: Rs-232 Protocols

    6.5 RS-232 Protocols CDPS-4H4HFS Remote Control Assignment Assignment ► ◄ Baud Rate: 115200bps Data bit: 8 bits Parity: None Flow Control: None Stop Bit: 1...
  • Page 17: Rs-232 Commands

    6.6 RS-232 Commands Command Name Description Description of parameter POWER OFF NONE POWER ON NONE IPCONFIG DISPLAY THE CURRENT NONE IPCONFIG SIPADDR XXX.XXX. SET ETHERNET IP AD- XXX=0~255 XXX.XXX DRESS SNETMASK XXX. SET ETHERNET XXX=0~255 XXX.XXX.XXX NETMASK SGATEWAY XXX. SET ETHERNET XXX=0~255 XXX.XXX.XXX GATEWAY...
  • Page 18 EDIDIN N1 N2 SET INPUT N1 EDID N1=1-4 SOURCE N2=0-9 HDCPIN SHOW ALL INPUT NONE HDCP STATUS HDCPIN N1 SHOW INPUT N1 HDCP N1=1-4 STATUS HDCPIN N1 N2 SET INPUT N1 HDCP N1=1-4 ON/OFF N2=(0)OFF (ON) PRESET SHOW ALL PRESET NONE CONFIG PRESET N1...
  • Page 19: Web Gui Control

    MATRIXMODE SHOW MATRIX NONE CURRENT MODE MATRIXMODE N1 SET MATRIX MODE N1=0-1 SHOW DESCRIPT OF NONE UNIT REBOOT SYSTEM REBOOT NONE HELP SHOW COMMAND NONE LIST HELP N SHOW DESCRIPT OF N : command name COMMAND Note: All the RS-232 command will be not executed unless followed with a carriage return.
  • Page 20 Click on Matrix Control for outputs and EIDID selections. Click on Settings to set each input’s HDCP Control and Preset Configuration.
  • Page 21 Click on Network Configuration to set the device’s IP configuration. Once the changes is saved the system will reset the IP address on the device automatically and user will need to re-enter the IP address to continue the Web GUI function.
  • Page 22: Connection Diagram

    7. CONNECTION DIAGRAM Blu-ray/DVD/ Blu-ray/DVD/ PS3 Players PS3 Players Blu-ray/DVD/ Blu-ray/DVD/ PS3 Players PS3 Players HDMI IN HDMI OUT SERVICE CONTROL RS232 IR IN DC 19V 60° OUT A IN 1 OUT B TAKE IN 2 OUT C CANCEL IN 3 OUT D PRESET IN 4...
  • Page 23: Specifications

    8. SPECIFICATIONS Frequency Bandwidth 340Mbps to 3Gbps Input Ports 4 x HDMI 1 x USB (Service only) 1 x Control 1 x RS-232 1 x IR Output ports 4 x HDMI Resolution 480i~1080p@50/60, 1080p@24, 4K x 2K (3840x2160/4096x2160@24Hz) Output Level VGA~WUXGA THD+N Frequency Response...
  • Page 24 DVI and HDMI Supported Resolutions Input Output 640x480@60 640x480@72 640x480@75 720x480@60 720x576p@50 800x600@60 800x600@72 800x600@75 1024x768@60 1024x768@70 1024x768@75 1280x720@50 1280x720@60 1280x720p@60 1280x768@60 1280x800@60 1280x1024@60 1360x768@60 1600x1200@60 1920x1080i@50 1920x1080i@60 1920x1080p@24 1920x1080p@25 1920x1080p@30 1920x1080p@50 1920x1080p@60 1920x1200@60(RB) 3840x2160@24/25/30 4096x2160@24...
  • Page 25: Acronyms

    Audio Sampling Rate Up to 192 kHz HDMI input (Up to 192kHz) HDMI output LPCM 2CH LPCM 5.1CH LPCM 7.1CH Dolby Digital 2~5.1CH/ DTS 2~5.1CH Dolby TrueHD/ DTS-HD Master Audio Audio Format LPCM 2/5.1/7.1CH,Dolby Digital 2~5.1CH, DTS 2~5.1CH (Pass through), Dolby TrueHD and DTS-HD Master Audio HDMI input HDMI output...
  • Page 28 CYPRESS TECHNOLOGY CO., LTD Home page: http://www.cypress.com.tw MPM-CDPS4H4HFS...
