Parts List - Watts SmartStream UV WB002 Installation, Operation And Maintenance Manual

Parts List

ITEM QTY. ORDERING CODE
1a 1 T7402050
1b 1 T7402044
1c 1 T7402039
1d 1 T7402038
2a 1 T7400148
2b 1 T7400149
2c 1 T7400150
2d 1 T7400151
2e 1 T7400152
2f 1 T7400153
2g 1 T7400154
2h 1 T7400155
2i 1 T7400156
2j 1 T7400157
2k 1 T7400158
3 1 T7401250
4a 1 T7401000
4b 1 T7402210
5 1 T7400147
6a 1 T7401104
6b 1 T7401105
6c 1 T7401106
6d 1 T7401107
6e 1 T7401109
6f 1 T7401110
6g 1 T7401111
6h 1 T7401113
6i 1 T7401114
7 1 T7402102
8a 1 T7401024
8b 1 T7401025
8c 1 T7401026
8d 1 T7401027
8e 1 T7401029
8f 1 T7401030
8g 1 T7401031
8h 1 T7401033
8i 1 T7401034
9 1 T7400145
10 1 T7400146
11 1 T7402025
12 12 T7402056
13a 1 T7401205
13b 1 T7401206
13c 1 T7401207
14 1 T7402032
15 1 T7402222
16a 1 T7401001
16b 1 T7401002
Bracket for Mounting 1-2 GPM UV Chamber
Bracket for Mounting 6-8 GPM UV Chamber
Bracket for Mounting 12-20 GPM UV Chamber
Bracket for Mounting 25-50 GPM UV Chamber
UV Chamber 2.5" OD 1 GPM 3/8" MNPT for B Series Controller
UV Chamber 2.5" OD 2 GPM 3/8" MNPT for B Series Controller
UV Chamber 2.5" OD 6 GPM 3/4" MNPT for B Series Controller
UV Chamber 2.5" OD 8 GPM 3/4" MNPT for B Series Controller
UV Chamber 3.5" OD 12 GPM 1" MNPT X 3/4" FNPT Combo for B Series Controller
UV Chamber 3.5" OD 12 GPM 1" MNPT X 3/4" FNPT Combo for C & D Series Controller
UV Chamber 3.5" OD 16 GPM 1" MNPT X 3/4" FNPT Combo for C & D Series Controller
UV Chamber 3.5" OD 20 GPM 1" MNPT X 3/4" FNPT Combo for C & D Series Controller
UV Chamber 4.0" OD 25 GPM 1 1/2" MNPT X 1" FNPT Combo for C & D Series Controller
UV Chamber 4.0" OD 40 GPM 1 1/2" MNPT X 1" FNPT Combo for C & D Series Controller
UV Chamber 4.0" OD 50 GPM 1 1/2" MNPT X 1" FNPT Combo for C & D Series Controller
Flow Switch with Cable for All Systems
UV Sensor Accessory Kit with Cable for C & D Series Controllers
Plug for UV Sensor Port when Sensor is Not Used
Spacer for Chamber
UV Quartz Sleeve for 1 GPM B Series 12.7" (324mm)
UV Quartz Sleeve for 2 GPM B Series 16.1" (409mm)
UV Quartz Sleeve for 6 GPM B Series 25.1" (639mm)
UV Quartz Sleeve for 8 & 12 GPM B Series 30.2" (769mm)
UV Quartz Sleeve for 12 GPM C & D Series 20.9" (531mm)
UV Quartz Sleeve for 16 GPM C & D Series 24.8" (631mm)
UV Quartz Sleeve for 20 & 25 GPM C & D Series 28.4" (722mm)
UV Quartz Sleeve for 40 GPM C & D Series 39.8" (1011mm)
UV Quartz Sleeve for 50 GPM C & D Series 46.9" (1192mm)
UV Quartz Sleeve O-Ring
UV Lamp Assembly for 1 GPM B Series
UV Lamp Assembly for 2 GPM B Series
UV Lamp Assembly for 6 GPM B Series
UV Lamp Assembly for 8 & 12 GPM B Series
UV Lamp Assembly for 12 GPM C & D Series
UV Lamp Assembly for 16 GPM C & D Series
UV Lamp Assembly for 20 & 25 GPM C & D Series
UV Lamp Assembly for 40 GPM C & D Series
UV Lamp Assembly for 50 GPM C & D Series
UV Quartz Sleeve Nut
UV Ring Nut
UV Antenna Housing
Wire Bushing
B Series Controller with Audible Alarm
C Series Controller with Alarm & 4-20 Milliamp Output
D Series Controller with Touch Screen Graphic Display
Pan Screw #8 X .375"
Power Cord 6' 120V Standard USA Plug with Ground
Solenoid Valve Accessory Kit 1" FNPT for 12-20 GPM Systems with C & D Series Controller
Solenoid Valve Accessory Kit 1 1/2" FNPT for 25-50 GPM Systems with C & D Series Controller
13
DESCRIPTION
