Installation, Operation and Maintenance Manual
CRITICAL NOTES for installing the Leak Defense System are highlighted in shaded boxes throughout the document.
It is essential these critical notes are read prior to installation.
VERY IMPORTANT!
•
Bracing may be required if your plumbing system is unable to support this weight.
•
Please contact our Technical Support team to confirm details of the installation to ensure the system will be installed
correctly and no water using appliances go unaccommodated.
WARNING
!
Please read carefully before proceeding with
installation. Your failure to follow any attached
instructions or operating parameters may lead to the
product's failure.
Keep this Manual for future reference.
INSTALLER
Please leave this guide with the homeowner
when installation is complete
Need help?
Feel free to call us from 8am - 5pm Monday - Friday
Pacific Time: (866) 410-1134, ext. 2
support@senthydro.com
IOM-S-Leak Defense
