Troubleshooting

If The Module Doesn't Configure or Appear Operational
•
Verify the module is installed in the panel correctly, in the proper location and that the pins on the circuit board are aligned
properly with the header on the main circuit board.
•
If these steps fail, try replacing the module devices or contact Interlogix Technical Support.
•
If range is limited, try replacing with a mobile device with longer range Bluetooth capability. Contact Interlogix Technical
Support.
If The Module Appears Operational, but Devices Connected To It Are Not
•
The programming for the device (ie., SmartPhone or tablet etc.) is most likely incomplete or failed or had an issue. Repeat the
device learn in process again. If failure continues, contact Interlogix technical Support.

Specifications

Module Compatibility
BlueTooth Device
Compatibility
Storage temperature
Operating temperature
Maximum humidity
Operating frequencies
Output Power
Bluetooth Version/Class
Bandwidth / Range

Regulatory Information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by UTC Fire and Security Americas Corporation, Inc. could void the user's
authority to operate the equipment.
In accordance with FCC requirements of human exposure to radiofrequency fields, the radiating element shall be installed such that
a minimum separation distance of 20 cm is maintained from the general population.
FCC: B4Z-962-BT
IC: 1175C-962DBT
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
AdvisorOne Bluetooth Module Installation Sheet
AdvisorOne Panel
Bluetooth-certified devices
-29 to 140ºF (-34 to 60ºC)
32 to 120ºF (0 to 49ºC)
85% relative humidity, noncondensing
Bluetooth: 2.4 GHz
Typical WLAN Transmit Power:
-
Bluetooth v4.0 BLE Class 1.5
Bluetooth range: 50 ft typical
