Installing The Bluetooth Module; Module Configuration And Programming - Interlogix AdvisorOne Bluetooth Installation Sheet

CAUTION: Use static electricity precautions when handling electronic components.
4. Disconnect the battery from the battery connector (E in Figure 2) by pressing down on the wire end of the battery clip.
5. Remove the Communication Modules Cover by pulling outward on the tabs (F in Figure 2) and then lifting upward when tabs
release.
6. To access the location of the Bluetooth module, remove the System Electronics Cover (this is the cover with a printed wiring
diagram) by pulling outward on the tabs (C in Figure 2), then disengaging the latch (D in Figure 2) with a small screwdriver and
lifting the cover upward when the latch releases.

Installing the Bluetooth Module

1. Install the Bluetooth module (A in Figures 1 and 3) into the Bluetooth module location (with the bar code label side up).
Carefully align the header of the module (B in Figures 1 and 3) with the pins on the main circuit board. Press into place.
Note: The Bluetooth module must be installed on the main board in the Bluetooth module location (A in Figure 3); it cannot be
installed in any other module location. DO NOT force the module into place.
2. Reinstall the System Electronics Cover, making sure the tabs (C in Figure 2) and the latch (D in Figure 2) are engaged.
3 Reinstall the Communication Modules Cover by pressing the cover down until the tabs (F in Figure 2) snap into place.
Note: All three internal covers must be secured for proper operation.
4. Supply power to the panel as noted in Table 2.
Table 2: Powering the Panel
Installation Action
US Plug the power supply into the outlet and secure with the supplied screw.
Canada Plug the power supply into the outlet.
All Other Installations Follow regional requirements.
Note: Connect the battery within 15 seconds of providing AC power to reduce the potential for a low battery indication.
5. Connect the battery to the battery connector on the panel (E in Figure 2). Note: The cable connector locks into place.
6 Close the panel, making sure all tabs are engaged. Replace the screw securing the panel chassis.
7. If the central monitoring station was notified, inform them this operation is complete.

Module Configuration and Programming

Module Configuration – Bluetooth Capability
No module configuration is required (i.e. no visibility timeout, pairing options etc.).
Programming
The Bluetooth capability of the module can be programmed to support key fob-like capability on a mobile device (Smartphone).
Note: The AdvisorSync Mobile software must be loaded onto the mobile device. For more information regarding loading
AdvisorSync Mobile, refer to the AdvisorSync Mobile Remote Installation Sheet (P/N 466-4424).
For more information on how to program the Bluetooth capability to work with AdvisorSync for Mobile Devices, refer to the
AdvisorOne Panel Install & Programming Manual (P/N 466-4405).
2 / 4
Note
Do not use the securement tab and screw.
AdvisorOne Bluetooth Module Installation Sheet
