Summary of Contents for Rose electronics CrystalView HDMI 4K60
-
Page 1: Operation Manual
CrystalView HDMI 4K60 4K60 HDBase-T Extender Installation Operation Manual 10707 Stancliff Road Phone: (281) 933-7673 Houston, Texas 77099 techsupport@rose.com... -
Page 2: Limited Warranty
CrystalView HDMI 4K60 extender to be in good working order for one year from the date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace the Unit as set forth below. -
Page 3: Declarations Of Conformity
DECLARATIONS OF CONFORMITY This is to certify that, when installed and used according to the instructions in this manual, the units listed and described here are shielded against the generation of radio interferences in accordance with the application of Council Directives 2014/30/EU and 2014/30/EU. This equipment has been found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Table Of Contents
Technical Support Figures Figure 1. Transmitter front and rear panels Figure 2. Receiver front and rear panels Figure 3. CrystalView HDMI 4K60 – installation diagram Figure 4. IR transmitter cable Figure 5. IR receiver cable Appendices Appendix A — Specifications... -
Page 5: Disclaimer
HDTV’s, or video projectors, with full support for high definition 7.1ch audio. The CrystalView HDMI 4K60 features bidirectional IR remote control extension, as well as full duplex RS-232 extension at baud rates up to 115,200 bps. The system utilizes PoC (Power over Cable), so a single power supply connected to either the Transmitter or Receiver can power the device at the other end. -
Page 6: Package Contents
Package Contents The package contents consist of the following items: CrystalView HDMI 4K60 transmitter and receiver units 1 x IR transmitter 1 x IR receiver 1 x 12VDC 2A power adapter with power cord Installation and operations manual. -
Page 7: Crystalview Hdmi 4K60 Units
MODELS CrystalView HDMI 4K60 Units The CrystalView HDMI 4K60 comes in a single model. The front and rear views of the transmitter and receiver units are shown below. CrystalView HDMI 4K60 Transmitter CrystalView HDMI 4K60 – transmitter unit front and rear panels 1. -
Page 8: Crystalview Hdmi 4K60 Receiver
CrystalView HDMI 4K60 Receiver CrystalView HDMI 4K60 – receiver unit front and rear panels 9. LED Indicators: From left to right Power indicator Link indicator HDMI Signal Indicator Front Panel Locking power jack: Connect to 12V DC... -
Page 9: Installing The Crystalview Hdmi 4K60 Extender
INSTALLATION and OPERATION Installing the CrystalView HDMI 4K60 Extender Installing the CrystalView HDMI 4K60 is a very simple and straightforward process. It is recommended that all equipment be powered off prior to beginning the installation. The installation steps are given below. -
Page 10: Safety
SAFETY Safety The CrystalView HDMI 4K60 Extender, like all electronic equipment, should be used with care. To protect yourself from possible injury and to minimize the risk of damage to the Unit, read and follow these safety instructions. Follow all instructions and warnings marked on this Unit. -
Page 11: Maintenance And Repair
This Unit does not contain any internal user-serviceable parts. In the event a Unit needs repair or maintenance, you must first obtain a Return Authorization (RA) number from Rose Electronics or an authorized repair center. This Return Authorization number must appear on the outside of the shipping container. -
Page 12: Appendices
FCC and CE certified, WEEE, RoHS compliant Approvals Appendix B — Part Numbers Part Numbers Description CRK-1DTX0H1-ASR/P CrystalView HDMI 4K60 Kit with Transmitter and Receiver CRK-SLDTX0H1-ASR/P CrystalView HDMI 4K60 Transmitter CRK-SRDTX0H1-ASR/P CrystalView HDMI 4K60 Receiver CAB-HDMIMM006 HDMI extension cable M/M, 6ft (2 m) - Page 13 ▪ ▪ WWW.ROSE.COM sales@rose.com (800) 333-9343 ▪ ▪ Rose Electronics 10707 Stancliff Road Houston, Texas 77099 Rose USA (281) 933-7673 ▪ Rose Europe +49 (0) 2454 969442 ▪ Rose Asia +65 6324 2322 Rose Australia +61 (0) 421 247083 WWW.ROSE.COM...
