CAPA110/111 AMD Embedded G-Series Processor Capa Board with LVDS
1.3

Utilities Supported

AMD G-Series APU dual core T56N 1.65 GHz
AMD G-Series APU dual core T40E 1.0 GHz
AMD G-Series APU single core T40R 1.0 GHz
AMD A50M
American Megatrends Inc. UEFI (Unified Extensible Firmware Interface) BIOS
16Mbit SPI Flash, DMI, Plug and Play
RPL/PXE Ethernet Boot ROM
One 204-pin unbuffered DDR3 SO-DIMM socket
Maximum to 4GB DDR3 1066 MHz memory for T40E/T40R
Maximum to 4GB DDR3 1333 MHz memory for T56N
Controller: Nuvoton W83627UHG
Serial Ports: One port for RS-232/422/485 and three ports for RS-232
Two SATA-600 connectors
One CompactFlash™ Type II Socket
Six USB ports with fuse protection and complies with USB Spec. Rev. 2.0
A slim type 15-pin D-Sub connector as VGA connector
One 40-pin connector for 18/24-bit single/dual channel LVDS
One Display Port (CAPA110 only)
1~255 seconds or minutes; up to 255 levels
Two ports with Realtek RTL8111E for Gigabit/Fast Ethernet
HD audio compliant (with speaker/line-out & line/MIC-in) with Realtek ALC662
Speaker/line-out & MIC-in & Line-in via Box Header connector
One PCI-Express Mini Card socket which complies with PCI-Express Mini Card spec
v1.2
ACPI(Advanced Configuration and Power Interface)
3.5" form factor
