Restore BIOS Optimal Defaults (JP1)

Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Function
2.3.2

LVDS Voltage Selection (JP2 and JP16)

Function
Properly configure jumper settings on the CAPA110/111 to meet your application purpose.
Function
Below you can find a summary table of all jumpers and onboard default settings.
Restore BIOS Optimal Defaults
JP1
Default: Normal Operation
2.3.3 CompactFlash™ Voltage Selection (JP5)
LVDS Voltage Selection
JP2
Default: +3.3V
CompactFlash™ Voltage Selection
JP5
Default: +3.3V
Function
JP6
COM1 RS-232/422/485 Mode Setting
JP9
Default: RS-232
JP10
COM1 Data/Power Selection
Default: RS-232 Data
(CAPA111)
2.3.4

COM1 RS-232/422/485 Mode Setting (JP6, JP9, JP10)

JP7
CN8 Data/Power Selection
Default: RS-232 Data
(CAPA110)
COM3 Data/Power Selection
JP8
Default: RS-232 Data
Function
COM2 Data/Power Selection
JP11
Default: RS-232 Data
COM4 Data/Power Selection
JP12
Default: RS-232 Data
Audio Output Selection
JP13
Default: Line Out
Auto Power On
JP15
Default: Disable
JP16 LVDS Voltage Selection
(Option) Default: +12V
Setting
JP2 Setting
JP16 Setting
Setting
Setting
1
2
3
COM1 Pin 1: DCD
COM1 Pin 9: RI
CN8 Pin 1: DCD
CN8 Pin 8: RI
CN7 Pin 1: DCD
CN7 Pin 8: RI
CN9 Pin 1: DCD
CN9 Pin 8: RI
CN7 Pin 11: DCD
CN7 Pin 18: RI
