1.3 Symbol Guide

The following symbols and safety labels are found on the UltraMaxO
Attention, consult accompanying
!
documents
Authorized representative in
EC REP
the European Community
Do not throw away. Follow local
guidelines for disposal
Evaluated by ETL (Intertek Testing
Laboratories)
Manufacturer
IPX1
Ingress protection
only Restricted to sale by or on order of a
medical professional
LATEX
Latex free
Serial number
SN
Catalog number
REF
Consult accompanying
documents

1.4 Component Description

3 1/2 Digit Display - The LCD provides direct readout of oxygen concentration, gas
flow and gas pressure. The LCD also displays error codes as necessary.
ON/OFF Button - Turns the device on or off.
Mode Button - Switches between measuring the concentration of gas produced by an
oxygen concentrator and pure oxygen (for calibration verification).
Low Battery Indicator – Indicates the voltage of the batteries is below normal
operating levels.
LPM – Illuminated next to the flow measurement. (Not shown when in calibration
verification mode).
KPA – Indicates the pressure measurement is in units of kilopascals.
PSI – Indicates the pressure measurement is in units of pounds per square inch.
2
866.4.Maxtec
On/off button
Mode button
Low battery
BAT
LPM
Liter per minute flow
PSI
Pounds per square inch
kPa
Kilopascals
%
Percent
Gas sample inlet
Gas sample outlet
Direct current
