- Page 1 Handi+ R 2 1 8 P 1 5 I N D U S T R I A L Operating Manual & Instructions For Use R218M15 REV. E...
- Page 2 Maxtec warrants to the original purchaser, that the HANDI+ analyzer to be free from defects in mate- rial and workmanship for a period of two-(2) years from the date of shipment from Maxtec or from one of Maxtec’s authorized dealers. Parts found to be defective as determined by Maxtec, will be repaired or replaced free of charge if shipped prepaid to the factory in the original shipping carton.
- Page 3 TABLE OF CONTENTS CLASSIFICATION ................II WARRANTY ...................II 1.0 INTRODUCTION ...............1 2.0 OPERATION ................1 2.1 General ....................1 3.0 CALIBRATION ................ 2 4.0 CALIBRATION ERRORS AND ERROR CODES ....2 5.0 CLEANING, MAINTENANCE, AND DISPOSAL ....3 6.0 SPECIFICATIONS ..............3 6.1 Analyzer Specifications ..............3 2.45 in 0.90 in 866.4.MAXTEC WWW.MAXTEC.COM...
- Page 4 Once the seal is removed, you should expect to obtain the normal life from the HANDI+. Included in the kit you will find the barbed adapter, which will screw onto the sensing port. HANDI Peel away seal Barbed Process Point Adapter which operates at 1 to 3 psig. Barbed Adapter 866.4.MAXTEC WWW.MAXTEC.COM...
- Page 5 Wait for displayed oxygen reading to stabilize when calibrating the device at 100% oxygen. Wait for unit to reach thermal equilibrium (Please note that this can take up to one half hour, if the device is stored in temperatures outside the specified operating temperature range). 866.4.MAXTEC WWW.MAXTEC.COM...
- Page 6 Press and hold the Calibration Button for three seconds to manually force a new calibration. If unit repeats this error more than three times, contact Maxtec Customer Service for possible replacement. CAL Err hi: Sensor voltage too high Press and hold the Calibration Button for three seconds to manually force a new calibration.
- Page 7 Weight: ................................Approx. 60 grams Battery Life: ......................Approx. 1850 hours (74,000 cycles) Sample Port: ................... M16 x1 Thread with barbed tubing adapter. Operating Pressure: ....................Atmospheric pressure to 3 psig Expected Storage Life: ................Two months with freshness seal on sensor. 866.4.MAXTEC WWW.MAXTEC.COM...
- Page 8 2305 South 1070 West Salt Lake City, Utah 84119 800.748.5355...
