Summary of Contents for Maxtec MaxO2 Plus
- Page 1 MAXO + AE Industrial ® MaxO ® O P E R A T I N G M A N U A L & I N S T R U C T I O N S F O R U S E R217M72 Rev.
-
Page 3: Classification
Product Disposal Instructions: The sensor, batteries, and circuit board are not suitable for regular trash disposal. Return sensor to Maxtec for proper disposal or dispose according to local guidelines. Follow local guidelines for disposal of other components. WARRANTY... -
Page 4: Warnings
This product will perform only as designed if installed and operated in accordance with the manufacturer’s operating instructions. » Use only genuine Maxtec accessories and replacement parts. Failure to do so may seriously impair the analyzer’s performance. Repair of this equipment must be performed by a qualified service technician experienced in repair of portable hand held equipment. -
Page 5: Table Of Contents
9.3.3 Carrying Options........10 866.4.Maxtec... -
Page 7: System Overview
Do not throw away. Follow local Percent guidelines for disposal. Manufacturer Calibration required REF Catalog Number Lot code/Batch code Do Not Serial Number Federal law (USA) restricts this IPX1 Drip Proof device to sale by or on the order only of a physician. 866.4.Maxtec www.maxtec.com... -
Page 8: Component Identification
This key is used to calibrate the device. Holding the key for more than three seconds will force the device to enter a calibration mode. Sample Inlet Connection - This is the port at which the device is connected to determine oxygen concentration. 866.4.Maxtec www.maxtec.com... -
Page 9: Max-250 Oxygen Sensor
3. Using the “ON/OFF” key, make sure the unit is in the power “ON” mode. 4. Allow the oxygen reading to stabilize. This will FIGURE 2 normally take about 30 seconds or more. 866.4.Maxtec www.maxtec.com... -
Page 10: Calibrating The Maxo
The MAXO + Analyzer should be calibrated upon initial power-up. Thereafter, Maxtec recommends calibration on a weekly basis. To serve as a reminder, a one week timer is started with each new calibration. At the end of one week a reminder icon “... -
Page 11: Direct Flow Calibration (Barb)
Therefore, the following are recommended: » Calibrate the MAXO + at the same pressure as the sample gas. » If sample gases flow through tubing, use the same apparatus and flow rates when calibrating as when measuring. 866.4.Maxtec www.maxtec.com... -
Page 12: Humidity Effects
E02: No sensor attached MAXO +AE: Disconnect and reconnect external sensor. Unit should perform an auto calibration, and should read 20.9%. If not, contact Maxtec Customer Service for possible sensor replacement or cable replacement. E03: No valid calibration data available Make sure unit has reached thermal equilibrium. -
Page 13: Changing The Batteries
Improper positioning could hinder the case halves from closing and prevent operation when tightening the screws. 866.4.Maxtec www.maxtec.com... -
Page 14: Changing The Oxygen Sensor
» Clean the sensor with a cloth moistened with isopropyl alcohol (65% alcohol/water solution). » Maxtec does not recommend use of spray disinfectants because they can contain salts, which can accumulate in the sensor membrane and impair readings. -
Page 15: Specifications
Sensor Type: ....... . . -
Page 16: Standard Replacement Parts
NOTE: Repair of this equipment must be preformed by a qualified service technician experienced in repair of portable hand held medical equipment. Equipment in need of repair shall be sent to: Maxtec Customer Service Department 2305 South 1070 West Salt Lake City, Ut 84119 (Include RMA number issued by Customer Service) 866.4.Maxtec...
