"%" symbol – Illuminated next to the concentration measurement.
Gas Sample Inlet – Used to receive the gas sample.
Gas Sample Outlet – Used as an outlet for the gas sample and as a trigger for pressure
measurement when occluded.
Gas Sample Tubing – Used to connect to gas sample sources.

2.0 OPERATING INSTRUCTIONS

2.1 Oxygen, Flow and Pressure Measurement

To check oxygen concentration, flow and pressure of a gas sample from a concentrator:
1. Connect the gas sample tubing to the gas sample inlet of the UltraMaxO
2. Attach the other end of the gas sample tubing to the oxygen concentrator.
3. Initiate the flow of gas to the UltraMaxO
per minute is recommended). Ensure the concentrator's output is stable per the
concentrator manufacturer's recommendations.
4. Turn on the UltraMaxO
5. Allow the oxygen reading to stabilize for approximately 10 seconds before reading
the oxygen concentration and flow.
6. To check pressure, cover the gas sample outlet with thumb or finger while gas is
flowing.
7. Wait 5 seconds for the display to read pressure.

2.2 Switching Pressure Units of Measure

The UltraMaxO
2
measure in PSI. To switch to kPa:
1. Using a #1 Phillips screwdriver loosen the battery door screw and remove the
battery door.
2. Toggle the switch inside the battery compartment.
3. Replace the battery door and tighten the battery door screw.

2.3 Calibration Verification Procedure

A calibration verification mode is provided to verify that the UltraMaxO
properly. To perform the calibration verification:
1. Turn on the UltraMaxO
2. Connect a source of pure oxygen ( ≥ 99.95%) to the gas sample inlet.
3. Flow 2-5 LPM of gas into the UltraMaxO
UltraMaxO
2
4. Press and hold the mode button. While holding the mode button, the gas
measurement should read between 98.5 and 101.5% oxygen. If the gas
measurement is not within this range, call Customer Service. Calibration
verification mode is indicated by "CAL" and "VER" flashing on screen beneath the
gas measurement .
2.
can measure pressure in PSI or kPa. The UltraMaxO
.
2
is at a stable temperature.
