6 Cabling and wiring

6.8 Bias VQ speakON

Bias VQ
Output
Max quantity per
channel

6.9 Bias D1/Q2 Phoenix wiring

-
Figure 6.8: Bias D1
Bias D1/Q2
Output
Max quantity per channel
Cyclone Series User Guide V1.0

wiring

TM
1+
1-
-
Figure 6.7: Bias VQ
Cyclone 10
Cyclone 55
Cyclone Bass
Cyclone 10
Cyclone 55
Cyclone Bass
1+
1-
+
Cyclone 10
Cyclone 55
Cyclone Bass
Cyclone 10
Cyclone 55
Cyclone Bass
1+
1-
+
-
Out 1 (Left)
LF (10") and HF (1")
LF (2 x 5") and HF (2 x 1") LF (2 x 5") and HF (2 x 1")
LF (12")
2 (4 Ω)
4 (4 Ω)
2 (4 Ω)
+
Out 3 (Right)
LF (10") and HF (1")
LF (12")
2 (4 Ω load to amplifier)
4 (4 Ω load to amplifier)
2 (4 Ω load to amplifier)
1+
1-
+
-
Figure 6.9: Bias Q2
Out 1
LF (10") and HF (1")
LF (2 x 5") and HF (2 x 1")
LF (12")
4 (2 Ω load to amplifier)
8 (2 Ω load to amplifier)
4 (2 Ω load to amplifier)
