5 Specifications and dimensions
5.2 Cyclone 55

5.2.1 Key features:

• Compact fibreglass enclosure
• Non-resonant structure
• Wide dispersion pattern
• Marine-grade stainless steel fittings
• UV resilient paint
• Custom colours available

5.2.2 Cyclone 55 specifications

Frequency response
Efficiency 1
Crossover points
Nominal impedance
Power handling
2
Maximum output
3
Driver configuration
Dispersion
Connectors
Height
Width
Depth
Weight
Enclosure
Rigging
Finish
1 Measured in half space 2 AES2 - 1984 compliant
Figure 5.4: Horizontal directivity isobars
Cyclone Series User Guide V1.0
70 Hz - 23 kHz ±3 dB
92 dB 1W/1m
3.6 kHz passive
16 Ω
120 W AES
110 dB cont, 114 dB peak
2 x 5" LF, 2 x 1" soft dome HF tweeters
110°H x 70°V
Phoenix connectors with link out
192 mm (7.6")
309 mm (12.2")
207 mm (8.1")
3.2 kg (7.1 lbs)
Fibreglass
Included Easy Hang wall bracket
Smooth cellulose
3 Calculated
Figure 5.5: Vertical directivity isobars
