5 Specifications and dimensions

5.3 Cyclone Bass

5.3.1 Key features:

• Compact fibreglass enclosure
• Marine-grade stainless steel fittings
• UV resilient paint
• Custom colours available.

5.3.2 Cyclone Bass specifications

Frequency response
Efficiency
1
Crossover points
Nominal impedance
Power handling 2
Maximum output 3
Driver configuration
Connectors
Height
Width
Depth
Weight
Enclosure
Finish
1 Measured in half space 2 AES2 - 1984 compliant
Cyclone Series User Guide V1.0
40 Hz - 160 Hz -3 dB
97 dB 1W/1m
80 Hz - 160 Hz Active
8 Ω
600 W AES
123 dB cont, 129 dB peak
1 x 12"
Phoenix connectors with link out
370 mm (14.6")
490 mm (19.3")
455 mm (17.9")
33.5 kg (73.9 lbs)
Fibreglass
Smooth cellulose
3 Calculated
