Summary of Contents for socomec DIRIS Digiware S

  • Page 1 DIRIS Digiware S Power Metering and Monitoring Device with integrated current sensors www.socomec.com/ en/diris-digiware...

  • Page 2: Table Of Contents

    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 4 .1 . DIRIS Digiware S current sensing module .
  • Page 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 4: Documentation

    1. Documentation All documentation relating to DIRIS Digiware and its associated sensors is available on the SOCOMEC website at the following address: www.socomec.com/en/diris-digiware DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 5: Hazards And Warnings

    • The auxiliary power supply voltage indicated on the device is observed: 24 VDC ± 15%. • The use of a SOCOMEC 230 VAC / 24 VDC power unit or a 24 VDC max 20 W class 2 power unit / SELV. The device must be protected with a 1A 24 VDC fuse.

  • Page 6: Responsibility

    • Any cable which needs to be replaced may only be replaced with a cable having the correct rating. • Despite constantly striving for quality in preparing this manual, errors or omissions are always a possibility and are not the responsibility of SOCOMEC. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 7: Preliminary Operations

    • The packaging is in good condition • The device has not been damaged during transit • The device part number matches your order • The packaging includes the device fitted with removable terminal blocks and a Quick Start Guide. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 8: Introduction

    • DIRIS Digiware I associated with TE, TR and TF sensors for the measurement from 5A up to 6000A This instruction manual only addresses DIRIS Digiware S modules. Please refer to the DIRIS Digiware manual for more information on other current measurement modules.

  • Page 9: Range

    Ref. 4829 0161 DIRIS Digiware U-30 DIRIS Digiware S-Datacenter Ref. 4829 0102 Ref. 4829 0162 io input/output modules Diris Digiware io-10 Diris Digiware io-20 Digital inputs/outputs analogue inputs DIRIS Digiware IO-10 DIRIS Digiware IO-20 Ref. 4829 0140 Ref. 4829 0145 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 10: Principle

    -> 1.5 mm 7 mm rs485 line Polarisation OFF = RS485 Line Polarisation disabled (by default) ON = RS485 Line Polarisation enabled SELV: Safety Extra Low Voltage (*) Earth should not be wired in unearthed systems DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 11 The Device must be fitted on insulated cables only: 300V or 600V insulation depending on the voltage level of the electrical installation Diris Digiware s Digiware bus termination DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 12: Functions

    • Voltage detection - On DIRIS Digiware S, three LEDs indicating the presence or the absence of voltage on each line - The voltage detection feature is only an indication and must not replace the use of a voltage tester.
  • Page 13 - FTPS export from the DIRIS Digiware D-70 display and DATALOG H80/H81 and FTP export from the DIRIS G-50 communication gateway - Auto detection and addressing of products connected downstream of the DIRIS Digiware D-xx displays and DIRIS G gateways DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 14: Electrical Readings

    Voltage dips /sags, swells and interruptions according to EN50160 • alarms Thresholds • History of average values • Format Width/Number of modules 18 mm / 1 18 mm / 1 18 mm / 1 Part number 4829 0105 4829 0106 4829 0102 DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 15 • advanced features Voltage detection • • • VirtualMonitor technology • • • AutoCorrect technology • • • Format Width 54 mm 54 mm 54 mm Part number 4829 0160 4829 0161 4829 0162 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 16: Dimensions

    Dual Dimensions in/mm 0.19 0.19 C-3x U-xx IO-xx 1.73 0.59 1.73 0.59 0.70 0.70 1.42 1.42 2.56 2.56 4.1.5.2. DIRIS Digiware S-xx Dual Dimensions in/mm 2.13 0.45 0.61 0.61 1.10 11.5 15.5 15.5 0.31 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 17: Installation

    0.29 or 0.59 in 7.5 or 15 mm 5 .2 .2 . DIRIS Digiware C, U, IO - back plate mounting 0.19 in 5 mm Type of screw: M4 Tightening torque: 0.5 Nm Washer diameter 0.47 in / 12 mm max. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 18: Diris Digiware S - Din Rail Mounting

    5 .2 .5 . DIRIS Digiware S holding • Temporary MCB insert: The DIRIS Digiware S module can be fixed and transported directly on top or under the protective device using a temporary insert tool: Step 1: Insert the tool through one of the current inputs and into the corresponding breaker terminal.

  • Page 19: Accessories Overview

    • Cable tie tethers: The DIRIS Digiware S module has 2 tethers which can be used with tightening clamps: The dimensions of the tightening clamp must not exceed 4 mm x 2 mm. 5 .2 .6 . Accessories overview Part number...

  • Page 20: Connection

    6. connection 6.1. Diris Digiware s connection Use rJ45 Digiware bus cables (UTP RJ45 straight, twisted pairs, unshielded, AWG24, 600V, Cat 5 rated, -10 / +70 °C) between all DIRIS Digiware modules. Do not put single insulated cables or active parts near the micro-USB or Digiware RJ45 port of the device.
  • Page 21 LIYCY-CY LIYCY-CY SLAVE MASTER 24 VDC 24 VDC (20 W max) (20 W max) (*) 1 A gG/Am fuse if using a non-SOCOMEC supply Diris Digiware c-31 Power supply Digiware bus communication line polarisation Diris Digiware c-32 Diris Digiware u Diris Digiware s...

  • Page 22: Connecting To The Electrical Network And Loads

    6.2. connecting to the electrical network and loads The DIRIS Digiware U-xx modules can be used on single-phase, two-phase or three-phase electrical networks. Each DIRIS Digiware S-xx current sensing module can use its three current inputs to simultaneously measure several loads, for example three single-phase loads.
  • Page 23 Below are some connection examples of the DIRIS Digiware S module: 6.2.2.1. DIRIS Digiware S-xx 3P+n - 3ct 3P - 3ct V1 V2 V3 VN V1 V2 V3 VN V1 V2 V3 VN V1 V2 V3 VN V1 V2 V3 VN...

  • Page 24: Connection Of The Functional Earth

    (class B in conducted emission). Earth must not be used in a neutral IT system. Earth must be connected on the DIRIS Digiware U module in order to use the voltage detection feature, the VirtualMonitor and AutoCorrect technologies. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 25: Digiware Bus

    • One DIRIS Digiware D remote display or one DIRIS Digiware C-31 system interface module • A DIRIS Digiware U voltage measurement module • One or multiple DIRIS Digiware S current sensing modules • One or multiple DIRIS Digiware IO input/output modules •...

  • Page 26: Digiware Bus Termination

    Use only SOCOMEC cables for the Digiware bus. 7 .1 .2 . Digiware Bus Termination 230VAC Quantity Part number 4829 0180 230VAC A DIRIS Digiware bus termination is supplied with each DIRIS Digiware D display and with each DIRIS Digiware C system interface module.

  • Page 27: Calculation Rules For The Max. Number Of Devices On The Digiware Bus

    Whenever the power consumption is higher than 20 W or the distance is greater than 100 m, a DIRIS Digiware C-32 repeater is required. In a DIRIS Digiware system, a maximum of 2 repeaters may be used. Diris Digiware c-32 repeater Part number 4829 0103 DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 28 C-32 S-xx 24 VDC 24 VDC Power supply Power supply The DIRIS Digiware U voltage module must be located upstream of the repeater. The repeater has a 24VDC power supply. Diris Digiware c-32 24VDC DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 29: Status And Auto-Addressing Leds

    1 (IN1) configured (IN1, IN2, IN3, IN4) which are in pulse counter mode configured in logical mode (*) Network rotation alarm possibly indicating a configuration error DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 30: Auto-Addressing

    Corresponds to the metrological pulse weight (1Wh by default) (**) System alarms for the DIRIS Digiware S module can be a bad V/I association indicating a possible wiring error. (***) By default, I01, I02, I03 LEDs are configured in voltage detection mode.

  • Page 31: Diris Digiware

    3 sec. Press 3 sec. The DIRIS Digiware U, DIRIS Digiware S, and DIRIS Digiware IO modules benefit from the auto- addressing mode. The auto addressing can be launched from the DIRIS Digiware D-40 / D-50 / D-70 remote displays or from the DIRIS G communication gateway.

  • Page 32: Communication

    A certain number of rules must be respected when DIRIS Digiware is connected using RS485. These rules are set out in the paragraphs below. Ethernet Digiware Bus Bus Digiware Termination DIRIS Digiware S DIRIS Digiware U RS485 RS485 120 Ω 120 Ω DIRIS G DIRIS B DIRIS Digiware C-31 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 33: Connection With The Diris Digiware C-31 System Interface Module

    DIRIS Digiware D-50 / D-70 COUNTIS You can show up to 32 devices on DIRIS Digiware D-50/D-70 display. Other connections are possible with the DIRIS Digiware D remote display; refer to its manual for more details. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 34: Connection With The Diris Digiware D-40 Remote Display

    You can show up to 32 devices on the DIRIS Digiware D-40 display. 9.3. communication tables The full communication tables for each module can be found on the SOCOMEC website at the following address: www.socomec.com/en/diris-digiware The communication tables are sent via JBUS (Modbus).
  • Page 35 Below is an extract of the DIRIS Digiware S-135 communication tables representing some instantaneous electrical parameters. Since a device can be configured to measure up to 3 loads, the Modbus registers are organized in 3 parts from load 1 to 3.
  • Page 36 Note 1: if one load (3P+N - 3CT) is configured, the Modbus registers related to loads 2 and 3 are not used and will return 0xFFFF. Note 2: if 3 loads (1P+N - 1CT) are configured, Modbus registers related to phase 2 and 3 (ex: V2, V3, I2, I3...) are not used and will return 0xFFFF. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 37: Configuration

    Easy Config Digiware Bus DIRIS Digiware S DIRIS Digiware U RS485 DIRIS DIRIS B-30 DIRIS Digiware D-40 / D-50 / D-70 COUNTIS RS485 * RS485 input only with DIRIS Digiware D-50 and D-70 displays DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 38 DIRIS B-30 DIRIS Digiware D-50 / D-70 COUNTIS RS485 These devices must be connected to the power supply before you configure them. For the Digiware bus and 120-ohm termination resistors, see section “Communication”, page 32. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 39: Using Easy Config

    In this menu, the user selects the type of network (three-phase, single-phase, etc.), the nominal voltage (must be correctly configured for the voltage detection feature to work properly), the network frequency, the direction of phase rotation and whether or not a voltage transformer is used. DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 40 Configuring the loads The number and type of loads can be accessed in the load configuration menu in the DIRIS Digiware S modules. The user can also define its nominal current, the name of the load, its usage and its location within the electrical installation.

  • Page 41: Synchronising Devices

    10 .2 .1 . Connection mode Configuration from the remote display (Digiware bus) Digiware Bus DIRIS DIRIS DIRIS Digiware D Digiware U Digiware S Refer to the manual for the DIRIS Digiware D display for more details. DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 42: Virtualmonitor Technology: Monitoring Of Protective Devices

    11. Virtualmonitor tecHnology: monitoring oF ProtectiVe DeVices DIRIS Digiware S modules embed the VirtualMonitor technology enabling an advanced real-time monitoring of protective devices (circuit breakers, fusible switches, fuses…) without using auxiliary contacts: • Position (open/closed) of the protective device • Trip information •...
  • Page 43 DIRIS Digiware S module downstream. This is illustrated in the architecture below: Thanks to its voltage detection capability, the DIRIS Digiware S module can detect the position of the protective device. An example corresponding to the above illustration is given in the table below:...

  • Page 44: Autocorrect Technology: Automatic Detection And Correction Of Wiring Errors

    • Changing phase association using the device’s front button Pressing the front button of the DIRIS Digiware S module for 5s will automatically correct the wiring and inform you with an LED sequence of the physical connection between the device’s current inputs and the network lines.
  • Page 45 This will be the case if the DIRIS Digiware S module is placed upstream (and turned upside down) of the protective device for example: • Advanced Wiring diagnostic from DIRIS Digiware D-xx displays: In the DIRIS Digiware D-xx displays, an advanced wiring diagnostic screen is available to help to detect wiring errors while configuring the DIRIS Digiware S module.

  • Page 46: Alarms

    - On all the phases simultaneously: Phase1 and Phase2 and Phase3 - On one phase of the three phases: Phase1 or Phase2 or Phase3 Example of configuring an alarm on the current via Easy Config: DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 47: Voltage And Current Unbalance (In A Three-Phase Network)

    This function is available on DIRIS Digiware IO-10. • Alarm upon change of status of a digital input • Choice of a rising or falling edge • Setting a time delay at the start and end of the alarm DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 48: Preconfigured Load Management Alarms (Only Available With Diris Digiware S-Datacenter)

    13 .1 .7 . Preconfigured load management alarms (only available with DIRIS Digiware S-Datacenter) DIRIS Digiware S-Datacenter has 9 preconfigured alarms, alerting the user of the load level on each current input: • Full load: when the load level reaches 80% of the nominal current.

  • Page 49: System Alarms

    If an installation error is detected during setup, a system alarm is automatically generated. 13 .3 .1 . Voltage/current association • Alarm upon connection error: wrong association between the current inputs of the DIRIS Digiware S module and the voltage inputs on the DIRIS Digiware U module 13 .3 .2 .

  • Page 50: Activation Of An Input

    • Information on the alarms with timestamping available via the RS485 communication bus • Sends alarm acknowledgement 13 .5 .4 . Display and Webview • Information on the alarms with timestamping • Sends alarm acknowledgement DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 51: Technical Characteristics

    Power factor measurement Accuracy Class 1 Voltage measurement - Diris Digiware u Characteristics of the network measured Nominal voltage: 480Y/277 VAC Range: 87-520 VAC (Ph/Ph); 50-300 VAC (Ph/N) CAT III Frequency range 45 - 65 Hz DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 52 Class 0.2 Connection Removable screw terminal block, 4 positions, stranded or solid 0.2 - 2.5 mm² cable Link with DIRIS Digiware S current sensing The first DIRIS Digiware S current sensing module is linked to the module DIRIS Digiware U voltage module by a Digiware Bus...

  • Page 53: Communication Characteristics

    The first DIRIS Digiware S current sensing module is linked to the DIRIS Digiware U voltage module by a Digiware Bus Link with DIRIS Digiware S current module The DIRIS Digiware S current modules are interconnected by the Digiware Bus with bus termination for the last module...

  • Page 54: Environmental Characteristics

    Front panel: 5J - casing: 1J (IEC 61010-1 Ed 3.0) PEP ecopassport - ISO 14025 DIRIS Digiware U: SOCO-2014-05-v1-FR, SOCO-2014-05-v1-EN DIRIS Digiware IO: SOCO-00001-V01.01-FR, SOCO-00001-V01.01-EN DIRIS Digiware S: SOCO-00006-V01.01-FR; SOCO-00006-V01.01-EN 14 .1 .8 . Electromagnetic characteristics Immunity to electrostatic discharges IEC 61000-4-2 LEVEL III...

  • Page 55: Diris Digiware D-40 Communication Characteristics

    24 VDC +10% / -20% SELV (Safety Extra Low Voltage) - 20 W max 14 .2 .6 . Environmental characteristics Storage temperature -20 … +70°C Operating temperature -10 … +55°C Humidity 95% at 40°C Installation category - degree of pollution CAT III, 2 DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 56: Performance Classes

    RMS value) Voltage harmonics THDi, Total harmonic distortion rate of the current (relative Rank 1 to 63 THD-Ri to the fundamental, relative to the RMS value) Current harmonics Centralised remote control signals DIRIS DIGIWARE - 546420C - SOCOMEC...

  • Page 57: Evaluation Of The Power Quality

    Voltage dip (Lp-Lg or Lp-N) Uswl Voltage swell (Lp-Lg or Lp-N) Uint Voltage interruption (Lp-Lg or Lp-N) Unba Voltage amplitude unbalance (Lp-N) Voltage phase and amplitude unbalance (Lp-Lg or Lp-N) Voltage harmonics Current harmonics Centralised remote control signals DIRIS DIGIWARE - 546420C - SOCOMEC...
  • Page 58 CORPORATE HQ CONTACT: SOCOMEC SAS 1-4 RUE DE WESTHOUSE 67235 BENFELD, FRANCE www.socomec.com 546420C...
