DIRIS A40/A41
RS485 – JBUS/MODBUS
®
Operating instructions
F
GB
D
I
NL
E
P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Diris A40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for socomec Diris A40

Summary of Contents for socomec Diris A40

  • Page 1 DIRIS A40/A41 RS485 – JBUS/MODBUS ® Operating instructions...
  • Page 2 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 3: Table Of Contents

    LAST 10 VOLTAGE CUT-OFFS EVENT LOG / SAG _______________________ 93 MEAN POWER EVENT LOG ___________________________________________ 95 MEAN VOLTAGE EVENT LOG __________________________________________ 95 MEAN FREQUENCY EVENT LOG ______________________________________ 95 TECHNICAL CHARACTERISTICS __________________________________________ 96 GLOSSARY OF ABBREVIATIONS __________________________________________ 96 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 4: Preliminary Operations

    General points The optional IP Communication module must be For a standard configuration, an RS 485 link is used to connected to the DIRIS A40/A41 (réf. : 4825 0201, connect up to 31 DIRIS or COUNTIS Ci with a PC or 4825 0202, 4825 1201, 4825 1202, 4825 U201, 4825 a PLC over a distance of 1200 metres, using JBUS/ 0207, 4825 0211, 4825 0213, 4825 0214�.

  • Page 5: Installation

    DIRIS A40/A41 - RS485 - JBUS/MODBUS ® INSTALLATION CONNECTION The module is fitted onto the back of the DIRIS A40/A41 in one of the 4 positions provided. The DIRIS A40/A41 must be switched off Fix the module in one of the four positions. Follow indications when connecting the terminal.

  • Page 6: Programming

    DIRIS A40/A41 - RS485 - JBUS/MODBUS ® PROGRAMMING Previous menu p.81 p.81 p.82 p.82 Following menu DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 7: Communication Address

    DIRIS A40/A41 - RS485 - JBUS/MODBUS ® PROGRAMMING COMMUNICATION ADDRESS > Example : COM ADR = 7 confirm COMMUNICATION SPEED > Example : BDS = 19 200 bauds confirm DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 8: Communication Parity

    DIRIS A40/A41 - RS485 - JBUS/MODBUS ® PROGRAMMING COMMUNICATION PARITY > Example : PAR = Even (Odd) (Even) (No) COMMUNICATION STOP BIT > Example : STOP = 2 x 1 (2 bits) x 2 (1 bits) confirm DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 9: Communication

    6 : to write one word. 8 : to diagnose exchanges between the master and the slave via meters 1, 3, 4, 5 and 6. 16 : to write n words (maximum 128�. DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 10: A : New Communication Table From 01/2009

    A : NEW COMMUNICATION TABLE FROM 01/2009 These new tables are available for all new Socomec products on sale from January 2009. The aim is to have common tables for common values, irrespective of the Socomec product. We recommend that you use these new tables whe- never possible for developing your applications.
  • Page 11 Σ active power - kW/100 51050 C76A avg Σ reactive power + kvar/100 51052 C76C avg Σ reactive power - kvar/100 51054 C76E avg Σ apparent power kVA/100 51056 C770 max/avg U12 V/100 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 12 2 +/- kvar/100 51301 C865 phase reactive power 3 +/- kvar/100 51302 C866 phase apparent power 1 kVA/100 51303 C867 phase apparent power 2 kVA/100 51304 C868 phase apparent power 3 kVA/100 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 13: Table C950Hex : Harmonics

    Harmonic I1 row 5 0,001 51552 C960 Harmonic I2 row 5 0,001 51553 C961 Harmonic I3 row 5 0,001 51554 C962 Harmonic IN row 5 0,001 51555 C963 Harmonic I1 row 7 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 14 Harmonic I3 row 31 0,001 51606 C996 Harmonic IN row 31 0,001 51607 C997 Harmonic I1 row 33 0,001 51608 C998 Harmonic I2 row 33 0,001 51609 C999 Harmonic I3 row 33 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 15 Harmonic I1 row 59 0,001 51660 C9CC Harmonic I2 row 59 0,001 51661 C9CD Harmonic I3 row 59 0,001 51662 C9CE Harmonic IN row 59 0,001 51663 C9CF Harmonic I1 row 61 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 16 Harmonic U23 row 29 0,001 51713 CA01 Harmonic U31 row 29 0,001 51714 CA02 Harmonic U12 row 31 0,001 51715 CA03 Harmonic U23 row 31 0,001 51716 CA04 Harmonic U31 row 31 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 17 51765 CA35 Max rank 51766 CA36 Harmonic V1 row 3 0,001 51767 CA37 Harmonic V2 row 3 0,001 51768 CA38 Harmonic V3 row 3 0,001 51769 CA39 Harmonic V1 row 5 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 18 Harmonic V3 row 37 0,001 51820 CA6C Harmonic V1 row 39 0,001 51821 CA6D Harmonic V2 row 39 0,001 51822 CA6E Harmonic V3 row 39 0,001 51823 CA6F Harmonic V1 row 41 0,001 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 19: Table E000 Hex : Primary Configuration

    1: 1 A 5: 5 A 3; 6; 16 57349 E005 CTN primary 3; 6; 16 57350 E006 Voltage input on TP : 0 : No 1: Yes – 3; 6; 16 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 20: Table E110 Hex : Ethernet Configuration

    JBUS/MODBUS gateway stop bits > Ethernet 3; 6; 16 57634 E122 Time out Jbus / Modbus > Ethernet 500 ms 3; 6; 16 57635 E123 JBUS slave address (RS485 & RTU over Ethernet� 1-247 3; 6; 16 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 21 A : NEW COMMUNICATION TABLE FROM 01/2009 9 > TABLE E220 Hex : Ethernet configuration Decimal Hex. No. of Description Unit JBUS function address address words available 57856 E200 Action : 0xA1 : Eeprom backup configuration 0xB2 : Product Reset 6; 16 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 22: B : Old Communication Table Before 01/2009

    Σ reactive power - kvar/100 max/avg Σ apparent power kVA/100 hour meter 1/100 h Active energy + Reactive energy + kvarh Apparent energy kVAh Active energy - Reactive energy - kvarh DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 23 19 : T°C 2 20 : T°C 3 21 : T°C internal 22 : T°C predicted 23 : T°C predicted 24 : T°C predicted Number of inputs-outputs Low-order: number of inputs High-order: number of outputs DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 24: Address Available With The Monitoring Or Control/Command Option

    To display all the values for DIRIS number 5 in one inquiry, the following frame should be sent: High-order Low-order High-order Low-order Slave Function CRC 16 address address word n° word n° C5A2 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 25: Table Of Values Without Allocated Current And Voltage Winding Ratios On 1 Word

    Σ active power + 1831 max/avg Σ active power - 1832 max/avg Σ reactive power + 1833 max/avg Σ reactive power - 1834 max/avg Σ apparent power 1835 Active energy + < 10000 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 26 1876 thd I3 0.10% 1877 thd In 0.10% 1878 thd U12 0.10% 1879 thd U23 0.10% 1880 thd U31 0.10% 1881 thd V1 0.10% 1882 thd V2 0.10% 1883 thd V3 0.10% DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 27 To display all the values for DIRIS number 5 in one inquiry, the following frame should be sent: High-order Low-order High-order Low-order Slave Function CRC 16 address address word n° word n° 44D1 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 28: Alarm Event Log

    3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 29 20 : thd U31 21 : HOUR 22 : V1 23 : V2 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 30 38 : ΣS predicted 1291 Alarm 1 OUT 1 upper threshold value – 1293 Duration 1294 Alarm 2 OUT 1 lower threshold – 0 : no alarm 1 : I1 2 : I2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 31 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 16 : thd I2 17 : thd I3 18 : thd U12 19 : thd U23 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 32 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 33 : T°C 2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 33 1307 Duration 1308 Current alarm OUT 2 lower threshold: – 0 : no alarm 1 : I1 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 34 15 : thd I1 16 : thd I2 17 : thd I3 18 : thd U12 19 : thd U23 20 : thd U31 21 : HOUR 22 : V1 23 : V2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 35 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 33 : T°C 2 34 : T°C 3 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 36 0 : no alarm 1 : I1 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 37 19 : thd U23 20 : thd U31 21 : HOUR 22 : V1 23 : V2 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 38 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 1330 Alarm 3 OUT 2 lower threshold value – 1332 Alarm 3 OUT 2 upper threshold: 0 : no alarm DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 39 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 40 21 : HOUR 22 : V1 23 : V2 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 41 38 : ΣS predicted 1345 Current alarm OUT 4 lower threshold value – 1347 Current alarm OUT 4 upper threshold: – 0 : no alarm 1 : I1 2 : I2 3 : I3 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 42 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 16 : thd I2 17 : thd I3 18 : thd U12 19 : thd U23 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 43 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 33 : T°C 2 34 : T°C 3 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 44 Current alarm OUT 6 upper threshold: – 0 : no alarm 1 : I1 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 45: Table Of Current And Voltage Harmonics

    Harmonic I3 row 3 0.10% 2317 Harmonic IN row 3 0.10% 2318 Harmonic I1 row 5 0.10% 2319 Harmonic I2 row 5 0.10% 2320 Harmonic I3 row 5 0.10% 2321 Harmonic IN row 5 0.10% DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 46 Harmonic V1 row 9 0.10% 2373 Harmonic V2 row 9 0.10% 2374 Harmonic V3 row 9 0.10% 2375 Harmonic V1 row 11 0.10% 2376 Harmonic V2 row 11 0.10% 2377 Harmonic V3 row 11 0.10% DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 47 Harmonic V3 row 23 0.10% 2431 Harmonic V1 row 25 0.10% 2432 Harmonic V2 row 25 0.10% 2433 Harmonic V3 row 25 0.10% Size of this zone : 130 words (decimal) or 82 (hexadecimal) DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 48: Option Recognition Table

    0xF0 : presence of IN measure Slot option 2 – Slot option 3 – Slot option 4 – Version number – Serial number – Size of this zone : 8 words (decimal) or 8 (hexadecimal) DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 49: List Of Parameters To Be Displayed Or Programmed

    0 : kWh + 1 : kvarh + 2 : kVAh 3 : kWh - 4 : kvarh - OUT1 impulse value: – 0 : 0.1 kWh/kvarh/kVAh 1 : 1 kWh/kvarh/kVAh 2 : 10 kWh/kvarh/kVAh DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 50 2 : I3 3 : In 4 : U12 5 : U23 6 : U31 7 : ΣP 8 : ΣQ 9 : ΣS 10 : ΣPFL 11 : V1 12 : V2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 51 21 : ΣS predicted 22 : T°C 1 23 : T°C 2 24 : T°C 3 25 : T°C internal Value at 0 or 4 mA from analog output OUT 2 – DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 52 0 : / 1 : k 2 : M Type of analog output OUT 4: – 0 : 0/20 mA 1 : 4/20 mA 2 : 30 V Output allocation analog OUT 4: – DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 53 9 : thd 3U 10 : IN 11 : HOUR 12 : V 13 : thd In 14 : thd 3V 15 : ΣP- 16 : ΣQ- 17 : ΣPFC 18 : Cd-t DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 54 23 : T°C 2 24 : T°C 3 25 : T°C internal Lower threshold OUT 2 – Unit lower threshold OUT 2: – 0 : / 1 : k 2 : M DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 55 Mean power memory storage Q- : 0 : no 1 : yes Mean power synchronisation signal : 0 : internal 1 : external Synchronisation period for P+, P-, Q+ et Q-: s. 300 : 5 minutes (5x60s� DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 56 Specified time OUT 3 Relay status OUT 3 : 0 : Open 1 : Closed Allocation of OUT 4 relay: 0 : Cde 1 : I 2 : U 3 : ΣP+ 4 : ΣQ+ DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 57 7 : ΣPFL 8 : thd 3I 9 : thd 3U 10 : IN 11 : HOUR 12 : V 13 : thd In 14 : thd 3V 15 : ΣP- 16 : ΣQ- DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 58 21 : T°C 3 22 : T°C internal 23 : ΣP predicted 24 : ΣQ predicted 25 : ΣS predicted Lower threshold OUT 6 Unit lower threshold OUT 6 : 0 : / DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 59 Configuration of a 4-wired unbalanced network (4 NBL� for DIRIS number 5. High-order Low-order High-order Low-order Slave Function CRC 16 address address word N° word N° 49F5 DIRIS A40/A41 reply: Identical to message sent. DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 60: Reset To Zero: Energy Meters And Max. Values

    Averaged out frequencies : 0 x 0080 Averaged out voltage values : 0 x 0100 Averaged out power values : 0 x 0200 Size of this zone: 3 words (decimals) and 3 (hexadecimals) DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 61: Saved Command

    DIRIS number 5. High-order Low-order Slave Function Values CRC 16 address address 0000 88C6 NB : The DIRIS A40/A41 responds with an identical frame. PULSE METERS VALUES Input meters Decimal Hexa. Number Text Unit address address of words...

  • Page 62: Date And Hour Settings

    32 : T°C 1 33 : T°C 2 34 : T°C 3 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 3090 Lower threshold value DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 63 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 3093 Upper threshold value 3095 Duration 3096 3097 Month 3098 Year 3099 Hour 3100 Minute 3101 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 64 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 65 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 3107 Upper threshold value 3109 Duration 3110 3111 Month 3112 Year 3113 Hour 3114 Minute 3115 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 66 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 67 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 16 : thd I2 17 : thd I3 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 68 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 69 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 33 : T°C 2 34 : T°C 3 35 : T°C internal DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 70 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 3149 Upper threshold value 3151 Duration 3152 3153 Month 3154 Year 3155 Hour 3156 Minute 3157 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 71 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 72 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 16 : thd I2 17 : thd I3 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 73 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 74 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC 32 : T°C 1 33 : T°C 2 34 : T°C 3 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 75 35 : T°C internal 36 : ΣP predicted 37 : ΣQ predicted 38 : ΣS predicted 3191 Upper threshold value 3193 Duration 3194 3195 Month 3196 Year 3197 Hour 3198 Minute 3199 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 76 2 : I2 3 : I3 4 : In 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 77 5 : U12 6 : U23 7 : U31 8 : ΣP+ 9 : ΣQ+ 10 : ΣS 11 : F 12 : ΣPFL 15 : thd I1 16 : thd I2 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 78 22 : V1 23 : V2 24 : V3 25 : thd In 26 : thd V1 27 : thd V2 28 : thd V3 29 : ΣP- 30 : ΣQ- 31 : ΣPFC DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 79 Value 3331 Query! : phase-to-neutral residual value : 22 : V1 23 : V2 24 : V3 3332 Value 3334 Duration 3336 3337 Month 3338 Year 3339 Hour 3340 Minute 3341 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 80 Query! : phase-to-neutral residual value : 0 : no 22 : V1 23 : V2 24 : V3 3360 Value 3362 Duration 3364 3365 Month 3366 Year 3367 Hour 3368 Minute 3369 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 81 Query! : phase-to-neutral residual value: 0 : no 22 : V1 23 : V2 24 : V3 3388 Value 3390 Duration 3392 3393 Month 3394 Year 3395 Hour 3396 Minute 3397 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 82 Query! : phase-to-neutral residual value : 0 : no 22 : V1 23 : V2 24 : V3 3416 Value 3418 Duration 3420 3421 Month 3422 Year 3423 Hour 3424 Minute 3425 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 83 Query! : phase-to-neutral residual value : 0 : no 22 : V1 23 : V2 24 : V3 3444 Value 3446 Duration 3448 3449 Month 3450 Year 3451 Hour 3452 Minute 3453 Second DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 84: Last 10 Voltage Dips Event Log / Sag

    Query! : maximum phase-to-neutral value : 0 : no 22 : V1 23 : V2 24 : V3 3588 Value 3590 Duration 3592 3593 Month 3594 Year 3595 Hour 3596 Minute 3597 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 85 Query! : maximum phase-to-neutral value : 0 : no 22 : V1 23 : V2 24 : V3 3616 Value 3618 Duration 3620 3621 Month 3622 Year 3623 Hour 3624 Minute 3625 Seconds DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 86 Query! : maximum phase-to-neutral value : 0 : no 22 : V1 23 : V2 24 : V3 3644 Value 3646 Duration 3648 3649 Month 3650 Year 3651 Hour 3652 Minute 3653 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 87 Query! : maximum phase-to-neutral value : 0 : no 22 : V1 23 : V2 24 : V3 3672 Value 3674 Duration 3676 3677 Month 3678 Year 3679 Hour 3680 Minute 3681 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 88 Query! : maximum phase-to-neutral value : 0 : no 22 : V1 23 : V2 24 : V3 3700 Value 3702 Duration 3704 3705 Month 3706 Year 3707 Hour 3708 Minute 3709 Second DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 89: Minimum And Maximum Instantaneous Values

    Second 3856 IN minimum 3858 3859 Month 3860 Year 3861 Hour 3862 Minute 3863 Second 3864 IN maximum 3866 3867 Month 3868 Year 3869 Hour 3870 Minute 3871 Second 3872 3U minimum DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 90 3924 Year 3925 Hour 3926 Minute 3927 Second 3928 ΣPF maximum 1 / 1000 3930 3931 Month 3932 Year 3933 Hour 3934 Minute 3935 Second 3936 ΣP + minimum kW / 100 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 91 3988 Year 3989 Hour 3990 Minute 3991 Second 3992 ΣQ - maximum kvar / 100 3994 3995 Month 3996 Year 3997 Hour 3998 Minute 3999 Second 4000 ΣS minimum kvar / 100 DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 92 Month 4052 Year 4053 Hour 4054 Minute 4055 Second 4056 THD 3U maximum 0.10 % 4058 4059 Month 4060 Year 4061 Hour 4062 Minute 4063 Second 4064 THD 3V minimum 0.10 % DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 93: Last 10 Voltage Cut-Offs Event Log / Sag

    Minute 4113 1011 Second Outage n-5 Decimal Hexa. Number Text Unit address address of words 4114 1012 4115 1013 Month 4116 1014 Year 4117 1015 Hour 4118 1016 Minute 4119 1017 Second DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 94 Number Text Unit address address of words 4150 1036 4151 1037 Month 4152 1038 Year 4153 1039 Hour 4154 103A Minute 4155 103B Second Zone size: 60 words (decimal) or 3C (hexadecimal). DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 95: Mean Power Event Log

    Unit address address of words 36864 9000 Frequency pointer 36865 9001 Date/Hour pointer updating 36868 9003 8700 Frequency values Hz/100 45568 B1FF Zone end Zone size: 8704 words (decimal) or 220 (hexadecimal). DIRIS A40/A41 - Ref.: 536 103 B GB...

  • Page 96: Technical Characteristics

    Certificate UL file No : E257746 GLOSSARY OF ABBREVIATIONS Communication Slave address Speed of communication in bauds Communication frame parity Without parity Even Even parity Odd parity STOP Frame-stop beep 1 stop bit 2 stop bits DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 97 DIRIS A40/A41 - RS485 - JBUS/MODBUS ® NOTES DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 98 DIRIS A40/A41 - RS485 - JBUS/MODBUS ® NOTES DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 99 DIRIS A40/A41 - RS485 - JBUS/MODBUS ® NOTES DIRIS A40/A41 - Ref.: 536 103 B GB...
  • Page 100 SOCOMEC - Ref.: 536 103 B GB - 05/12 Socomec worldwide ThE UnITED KInGDOM SOCOMEC Ltd UK - Knowl Piece - Wilbury Way Hitchin Hertfordshire SG4 0TY Tel. 01462 440033 Fax 01462 431143 info.scp.uk@socomec.com In EUROPE In ASIA In MIDDLE EAST...
