IntelliPack Series 801T Transmitter/Alarm User's Manual
___________________________________________________________________________________________
Safety Summary - Symbols on equipment:
Means "Caution, refer to this manual for additional
!
information".
The information contained in this manual is subject to change
without notice. Acromag, Inc., makes no warranty of any kind
with regard to this material, including, but not limited to, the
implied warranties of merchantability and fitness for a particular
purpose. Further, Acromag, Inc., assumes no responsibility for
any errors that may appear in this manual and makes no
commitment to update, or keep current, the information contained
in this manual. No part of this manual may be copied or
reproduced in any form, without the prior written consent of
Acromag, Inc.

Table of Contents

1.0 INTRODUCTION ..............................................
DESCRIPTION ................................................
Key IntelliPack 801T Features...........................
ACCESSORY ITEMS ........................................
IntelliPack Serial Port Adapter ..........................
IntelliPack Cable.............................................
AC Current Sensor .........................................
2.0 PREPARATION FOR USE .................................
UNPACKING AND INSPECTION ........................
INSTALLATION ...............................................
Mounting ......................................................
Electrical Connections ....................................
3.0 MODULE CONFIGURATION .............................
4.0 THEORY OF OPERATION ................................
5.0 SERVICE AND REPAIR ....................................
6.0 SPECIFICATIONS ...........................................
MODEL NUMBER DEFINITION...........................
INPUT SPECIFICATIONS ..................................
RELAY OUTPUT SPECIFICATIONS....................
APPROVALS ..................................................
SOFTWARE CONFIGURATION...........................
List of Drawings
Simplified Schematic (4501-680)...............................
Functional Block Diagram (4501-689).........................
Electrical Connections (4501-681)..............................
Enclosure Dimensions (4501-642) .............................
REVISION HISTORY...............................................
Windows 95 & NT are registered trademarks of Microsoft Corp.
IMPORTANT SAFETY CONSIDERATIONS
It is very important for the user to consider the possible adverse
effects of power, wiring, component, sensor, or software failures
in designing any type of control or monitoring system. This is
especially important where economic property loss or human life
is involved. It is important that the user employ satisfactory
overall system design. It is agreed between the Buyer and
Acromag, that this is the Buyer's responsibility.

1.0 INTRODUCTION

These instructions cover hardware functionality of the
transmitter models listed in Table 1. Supplementary sheets are
attached for units with special options or features.
Table 1: Models Covered in This Manual
Page
Series/
Input/Type
2
801T
2
801T
3
4
Notes (Table 1):
4
1.
Agency approvals include cULus Listed.
4
Include the "-C" suffix to specify factory configuration option.
2.
4
Otherwise, no suffix is required for standard configuration.
4
3.
Model 801T-0500 units have transmitter functionality only,
4
while 801T-1500 transmitters include an alarm relay.
4
4
4
Module programming, transmitter operation, and the
5
IntelliPack Configuration Software is covered in the IntelliPack
5
Transmitter Configuration Manual (8500-570).
5
5

DESCRIPTION

6
7
Series 801T Transmitters and combination Transmitter/
7
Alarms are members of the popular Acromag IntelliPack
7
transmitter & alarm family. These models will condition DC
7
8
voltage, thermocouple, or RTD inputs. The transmitter output is
8
an isolated process current or voltage, plus an optional Single-
8
Pole Double-Throw (SPDT) electro-mechanical alarm relay
9
(Model 801T-1500). All IntelliPacks contain an advanced
10
technology microcontroller with integrated downloadable flash
10
memory and EEPROM for non-volatile program, configuration,
10
calibration, and parameter data storage. Units are fully
10
reconfigurable via our user-friendly Windows 95
11
IntelliPack Configuration Program. Field reconfigurability is also
11
possible with module push-buttons and status LED's. Once
11
configured, these modules may operate independent of the host
Page
computer for true embedded monitoring and control.
13
14
Each module provides a single input for either DC millivolts,
15
thermocouple, or RTD signals. RTD sensor excitation,
16
linearization, lead-wire compensation, and lead break detection
17
are included. Thermocouple reference-junction compensation,
18
linearization, and open circuit or TC break detection is also
19
provided. Model 801T Transmitters provide an isolated process
current or voltage output and Model 801T-1500 units include an
isolated alarm relay. The relay has a yellow LED on the front of
the module that provides a visual indication of the high or low
alarm condition. Additionally, green "Run", yellow "Status", and
"Zero/Full-Scale" LED's provide local feedback of operating
mode, system diagnostics, and field configuration status.
- 2 -
mV/TC/RTD Input
-Options/Output/
-Factory
1
Enclosure/Approvals
Configuration
3
-0500
-C
3
-1500
-C
2
or NT
