Connecting to Power

UPS
(Optional)
DC
Power
NOTE
Use a power adapter that has a DC 12 V (± 10%) specification of with the minimum current of 1,500 mA and has IEC/EN 60950-1
•
certification. If the power adapter is shared by other devices, the power adapter should provide a current more than the sum of the
power consumption from this device (1,500 mA) and other devices.
Use a separate power supply for Secure I/O 2, electric lock and BioEntry Plus respectively. If connecting and using the power supply
•
to these devices together, the devices may malfunction.
1 - PWR +VDC Red
2 - PWR GND Black
9
Installation
1
2
BioEntry Plus
