Product Contents Front Panel Description Rear Panel Description Connectors for External Interfaces Contents Installation Example Product Dimension Power Connection RS-485 Connection Relay Connection RTE Switch Connection Fire Alarm Connection System Specifications ⒸCopyright 2010 Suprema Inc.
SYNC BUTTON - Syncronization between Secure I/O and dev ice (BioStation/ BioEntry Plus) for security by exchanging an e ncryted keys. This prevents the operation of Secure I/O when the external device has been exchanged by an intruder. Sync button should be pressed when a device is set as a host in a RS-485 loop.
Rear Panel Description ID0 / ID1 - Dip switch to set an ID of Secure I/O Since max number of Secure I/O in an RS-485 loop is four, the ID of Secure I/O should be set among 0, 1, 2, 3.
IN 2+ Relay Output1 Common N.C 1 IN 2- Relay Output1 Normal Close TRX+ IN 3+ RS-485 TRX+ TRX- IN 3- RS-485 TRX- SYNC TRXGND RS-485 Ground Frame Ground FGND PWR+ Power Input+ PWR- Power Input - ⒸCopyright 2010 Suprema Inc.
Page 7
RESET COM 1 IN 2+ External Input 2 + N.C 1 IN 2- External Input 2 - TRX+ IN 3+ External Input 3 + TRX- IN 3- External Input 3 -- SYNC TRXGND FGND PWR+ PWR- ⒸCopyright 2010 Suprema Inc.
DC 12V Negative Recommended power supply 12V ± 10%, at least 500mA for Secure IO alone installation. Comply with standard IEC/EN 60950-1 To share the power with other devices, use a power supply with higher current ratings. ⒸCopyright 2010 Suprema Inc.
RS-485 Ground TRXGND PWR+ BioStation or BioEntry Plus PWR- In case the length of RS-485 line is so long to affect communication stability, connect the enclosed 120 Ohm resistor between TRX+ and TRX- connector of Secure I/O ⒸCopyright 2010 Suprema Inc.
Source Door Strike When using dead bolt or door strike, connect an enclosed diode as in the above diagram. Anode (line mark) of the diode should be connected to + power (Be careful of the direction) ⒸCopyright 2010 Suprema Inc.
Page 13
Source Door Strike When using dead bolt or door strike, connect an enclosed diode as in the above diagram. Anode (line mark) of the diode should be connected to + power (Be careful of the direction) ⒸCopyright 2010 Suprema Inc.
Product size : 142.5 x 110 x 39 mm (width x length x depth) Min. Typ. Max. Notes Power Voltage (V) 10.8 13.2 Current (mA) Relay 125VAC Normal switching 250VAC capacity(N.O) (Resistive) 30VDC 125VAC Normal switching 250VAC capacity(N.C) (Resistive) 30VDC ⒸCopyright 2010 Suprema Inc.
Page 17
16F Parkview Office Tower, Jeongja-dong, Bundang-gu, Seongnam, Gyeonggi, 463-863 Korea E-mail : support@supremainc.com Website : www.supremainc.com Functions and specifications of the product are subject to changes without notice due to quality enhancement or function update. For any inquiry on the product, please contact Suprema Inc.
