Parts List - Linear Technology LT3507A Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 3 CIN1, CIN2, CIN3
2 1 C1
3 2 C2, C9
4 2 C3, C10
5 1 C4
6 3 C5, C6, C11
7 4 C7, C8, C13, C20
8 1 C12
9 3 C15, C17, C19
10 1 D4
11 2 D5, D6
12 3 D7, D8, D9
13 1 L1
14 1 L2
15 1 L3
16 1 Q1
17 5 R1, R2, R3, R15, R22
18 1 R4
19 1 R5
20 3 R6, R7, R11
21 3 R8, R9, R23
22 1 R10
23 1 R12
24 1 R13
25 1 R14
26 1 R16
27 1 R17
28 1 R18
29 1 R19
30 1 U1
DEMO MANUAL DC1781A
PART DESCRIPTION
CAP ., X7R, 2.2μF , 50V, 10%, 1210
CAP ., X7R, 0.47μF , 25V, 10%, 0603
CAP ., X7R, 0.22μF , 25V, 10%, 0603
CAP ., X5R, 47μF , 10V, 20%, 1206
CAP ., X5R, 22μF , 6.3V, 20%, 1206
CAP ., X7R, 680pF , 50V, 10%, 0402
CAP ., X5R, 0.1μF , 10V, 10%, 0402
CAP ., X5R, 2.2μF , 6.3V, 20%, 0603
CAP ., NPO, 47pF , 50V, 5%, 0402
DIODE, SCHOTTKY, B340A, SMA-DIODE
DIODE, SCHOTTKY, B240A, SMA-DIODE
DIODE, SCHOTTKY, CMDSH-4E, SOD323
IND., 4.7μH
IND., 8.2μH
IND., 10μH
XTOR, NPN, 50V LOW SATURATION, MLP322
RES., CHIP , 100k, 1/16W, 1%, 0402
RES., CHIP , 12.4k, 1/16W, 1%, 0402
RES., CHIP , 31.6k, 1/16W, 1% 0402
RES., CHIP , 20k, 1/16W, 1% 0402
RES., CHIP , 10k, 1/16W, 1% 0402
RES., CHIP , 53.6k, 1/16W, 1% 0402
RES., CHIP , 10.2k, 1/16W, 1% 0402
RES., CHIP , 1.07k, 1/16W, 1% 0402
RES., CHIP , 49.9k, 1/16W, 1% 0402
RES., CHIP , 499, 1/16W, 1% 0402
RES., CHIP , 18.2k, 1/16W, 1% 0402
RES., CHIP , 3.32k, 1/16W, 1% 0402
RES., CHIP , 107k, 1/16W, 1% 0402
I.C., LT3507EUHF , QFN38UHF
MANUFACTURER/PART NUMBER
TDK, C3225X7R1H225K
MURATA, GRM188R71E474KA12D
TDK, C1608X7R1E224K
TAIYO YUDEN, LMK316BJ476ML-T
TAIYO YUDEN, JMK316BJ226ML
AVX, 04025C681KAT
AVX, 0402ZD104KAT
TAIYO YUDEN, JMK107BJ225MA
AVX, 04025A470JAT
DIODES INC., B340A
DIODES INC., B240A
CENTRAL SEMI., CMDSH-4E
NIC, NPIM74C4R7MTRF
NIC, NPIM74C8R2MTRF
NIC, NPIM74C100MTRF
ZETEX, ZXTCM322TA
YAGEO, RC0402FR-07100KL
VISHAY, CRCW040212K4FKEA
VISHAY, CRCW040231K6FKEA
VISHAY, CRCW040220K0FKEA
YAGEO, RC0402FR-0710KL
VISHAY, CRCW040253K6FKEA
NIC, NRC04F1022TRF
YAGEO, RC0402FR-071K07L
VISHAY, CRCW040249K9FKEA
AAC, CR05-4990FM
VISHAY, CRCW040218K2FKEA
VISHAY, CRCW04023K32FKEA
AAC, CR05-1073FM
LINEAR TECH., LT3507EUHF
dc1781af
5
