Useful adjustment settings

Input signal source

TV CBL VCR DVD
/SAT /LD
TV
/DTV
POWER ANT-A/B INPUT
AV FRONT
MODE SURROUND MTS CC
TWIN
SELECT
VIEW SUB TWIN CH
MODE FREEZE INPUT
DISPLAY SLEEP EDIT/ LEARN
Input selection
Can use for selecting the input source.
1
Press INPUT on the remote control unit or
on the Display.
2
Press INPUT on the remote control unit or
on the Display to select the input source.
• An image from the selected source
automatically displays.
• You can also select the input source by
pressing a/b.
NOTE
• Some items may be grayed out. They are not selectable.
Input signal setting
For setting the signal type of external equipment
connected to INPUT 1 or 3 terminals.
1
Press MENU and the TV MENU screen
displays.
2
Press c/d to select "Option".
• Option menu displays.
3
Press a/b to select "Input Select", and then
press SET/ENTER.
4
Press a/b to select a signal type you want
to set, and then press SET/ENTER.
• If the selected signal type is incorrect, an image
does not display or no color image displays.
NOTE
• The System automatically sets input signals from
"INPUT2", "INPUT4" and "PC".
• If no (color) image displays, try to change the signal
type.
• Check the operation manual of the external equipment
for the signal type.
• Setting INPUT 1 and INPUT 3 signal selection to "Auto"
when other equipment is connected will result in the
following connectivity priority.
INPUT 1
1. COMPONENT VIDEO
2. S-VIDEO
3. VIDEO
50
MENU TV/SAT/DVD DTV/DVD TOP
RETURN MENU MENU
SOURCE DTV/SAT
POWER GUIDE
SET/
ENTER
DTV/SAT
INFO
VCR REC
FAVORITE CH
A B C D
POWER INPUT VOL VOL
RECEIVER
INPUT 3
1. COMPONENT VIDEO
2. S-VIDEO
3. VIDEO
4. DVI
DVI input signal setting
Selecting the image resolution of the DVI-DIGITAL input
signal.
The DVI-DIGITAL terminal of this System supports the
HDCP* standard.
1
Press INPUT on the remote control unit or
on the Display and select "INPUT3", as
explained in Input selection.
2
Select "Auto" or "DVI" from the "Input Select"
menu for INPUT 3 signals, as explained in
Input signal setting.
3
Press MENU and TV MENU screen displays.
4
Press c/d to select "Setup".
5
Press a/b to select "Input Signal", and then
press SET/ENTER.
TV MENU
Setup

Input Signal

Parental CTRL

Position

Picture Flip
Language
6
Press c/d to select a signal type you want
to set, and then press SET/ENTER.
TV MENU
Setup
Input Signal
VGA
NOTE
• * What is HDCP (High-Bandwidth Digital Content
Protection)?
• HDCP is a copyright protection technology that uses
TMDS (Transmission Minimized Differential Signal).
• HDCP was developed to prevent the illegal copying of
DVI signals.
Option
[VGA]
[Standard]
[English]
480p
