Using external equipment

Watching a VCR image

Connecting a VCR

You can use the INPUT 2 terminal when connecting a VCR and other audiovisual equipment.
AVC System (rear view)
TV
TV
ANT-A/B
POWER
AV FRONT
MODE SURROUND
TWIN
VIEW
MODE FREEZE
DISPLAY SLEEP
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
PC
AV cable
(commercially available)
S-VIDEO cable
(commercially available)
CBL VCR DVD
/SAT /LD
/DTV
INPUT
MTS CC
SELECT
SUB TWIN CH
INPUT
EDIT/ LEARN

Displaying a VCR image

To watch a VCR image, select "INPUT2" from the
"INPUT SOURCE" menu using INPUT on the remote
control unit or on the Display. (See page 50.)
When connecting to the INPUT 2 terminals, select
"INPUT2".
You only need to select the input source on the "INPUT
SOURCE" menu.
NOTE
• Each time INPUT is pressed, the input source toggles.
• Refer to your VCR operation manual for the signal type.
VCR
