DEMO MANUAL DC2276A
parts list
ITEM
QTY
REFERENCE
Required Circuit Components
1
2
C1,C2
2
1
C3
3
1
C4
4
1
C5
5
1
R1
6
1
R2
7
1
R3
8
1
R4
9
1
R5
10
1
R6
11
1
R7
12
1
R9
13
1
R10
14
1
R11
15
1
U1
Additional Demo Board Circuit Components
16
0
C5 (OPT)
17
0
R8, R12, R13 (OPT)
Hardware: For Demo Board Only
18
8
E1-E8
19
1
JP1
20
1
JP2
21
2
JP3-JP4
22
4
XJP1-XJP4
6
PART DESCRIPTION
CAP., X5R, 10µF, 50V, 10%, 1206
CAP., X7R, 0.1µF, 25V, 10%, 0603
CAP., ALUM, 10µF, 50V, 20%
CAP., X7R, 1µF, 10V, 10%, 0603
RES., CHIP, 5.1k, 1/10W, 5%, 0603
RES., CHIP, 49.9k, 1/8W, 1%, 0805
RES., CHIP, 24.9k, 1/10W, 1%, 0603
RES., CHIP, 49.9k, 1/10W, 1%, 0603
RES., CHIP, 100k, 1/10W, 1%, 0603
RES., CHIP, 243k, 1/10W, 1%, 0603
RES., CHIP, 301k, 1/10W, 1%, 0603
RES., CHIP, 1.58k, 1/10W, 1%, 0603
RES., CHIP, 806, 1/10W, 1%, 0603
RES., CHIP, 0, 1/10W, 0603
I.C., REGULATOR, DFN14
CAP., OPTION, 1206
RES., OPTION, 0603
TESTPOINT, TURRET, .094" PBF
HEADER 2x2 PIN 0.079 DOUBLE ROW
HEADER 6x2 PIN 0.079 DOUBLE ROW
HEADER 3x2 PIN 0.079 DOUBLE ROW
SHUNT, 0.079" CENTER
MANUFACTURER/PART NUMBER
MURATA, GRM31CR61H106KA12L
MURATA, GRM188R71E104KA01D
SUN ELECT, 50CE10BSS
MURATA, GRM188R71A105KA61D
VISHAY, CRCW06035K10JNEA
VISHAY, CRCW080549K9FKEA
VISHAY, CRCW060324K9FKEA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW0603100KFKEA
VISHAY, CRCW0603243KFKEA
VISHAY, CRCW0603301KFKEA
VISHAY, CRCW06031K58FKEA
VISHAY, CRCW0603806RFKEA
VISHAY, CRCW06030000Z0EA
LINEAR TECH, LT3091EDE#PBF
MILL-MAX, 2501-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000421121
SAMTEC, TMM-106-02-L-D
WURTH ELEKTRONIK, 62000621121
WURTH ELEKTRONIK, 60800213421
dc2276af
