Topeak NINJA C User Manual

Rivet Anvil
of hollow pin
Adjusting Knob and
Chain Pin Breaker
Rubber Ring
HOW TO STORE NINJA C IN HANDLEBAR
1
Handlebar with minimum 70 mm straight
section end
ROAD HANDLEBARS
70
mm
STEP 1
(Example for grips with end caps)
Loosen bolt and remove end cap of grip on both
sides. (Depends on the type of handlebar)
HOW TO REMOVE NINJA C FROM HANDLEBAR
PULL OUT
NINJA C
Chain Hook
Cap
FLAT BARS
70
mm
STEP
Turn the cap to expand the
rubber ring as little as necessary.
4 mm Allen Key
(Chain
Pin is not
included)
Chain Pin x 2
Compartment
LIMITATIONS
2
Fits inner ø 16.5-20 mm tube
16.5
ø mm
20
ø mm
2
If NINJA C does not fit properly into handlebar, adjust
tension of rubber ring as necessary and reinstall.
Periodically check that NINJA C is seated in
handlebar properly.
User's Guide
GB
• Fits Road handlebar with
70
minimum mm straight
section end.
16.5-20
• Fits inner ø
• Fits multi-speed chains up to
Campagnolo® 11 speed hollow
pin chain.
• Please read these instructions
before first use.
MAINTENANCE
• Lubricate and maintain tool with Teflon®
based lubricant as needed.
• To prevent rusting, keep tool dry.
3
Fits grips with
end caps
STEP
PUSH
Push NINJA C into the end
Press to adjust
the shape of
of handlebar on both sides.
rubber ring as
shown.
WARNING
mm tube.
3
