Compact Handlebar Bag
Art no. TT3020B
BarPack
Art no. TC2702B
MOUNTING INSTRUCTIONS
Fits ø25.4, ø28.6 and ø31.8 mm handlebars.
2
1
3
1a
4
DETAILED PARTS DESCRIPTION
Handlebar Bag Fixer
1. HB Fixer A
1a. HB Fixer Release Button
2. M5 x 20mm Bolt
3. M5 x 15mm Bolt
4. M5 x 12mm Bolt
5. HB Fixer B
* Not needed if handlebar diameter is 31.8mm.
Handlebar Bag
TourGuide Handlebar Bag
TourGuide Handlebar Bag DX
Art no. TT3021B
Art no. TT3022B
Handlebar DryBag
Art no. TT9805B
5
7a
7b
6a
6
6b
6. Computer Clip
6a. Thread hole
6b. Computer Clip Release Tab
7. Rubber Sizing Pad
*
7a. ø25.4 (for normal size h/bar)
7b. ø28.6 (for oversize h/bar)
8. Security Cable
8a. cable housing
series
Tighten the bolts.
8
(Do not tighten completely.)
8a
M5 x 20L
Bolt
User's Guide
Mount Handlebar Fixer on Handlebar
5mm Allen key
GB
20˚
Add cable housing over the
security cable to protect the
stem from marring. Trim
excess cable housing.
Prepare to Ride

Advertisement

loading
Need help?

Need help?

Do you have a question about the TT3020B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Topeak TT3020B

  • Page 1 Handlebar Bag User's Guide series Mount Handlebar Fixer on Handlebar Compact Handlebar Bag TourGuide Handlebar Bag TourGuide Handlebar Bag DX Art no. TT3020B Art no. TT3021B Art no. TT3022B BarPack Handlebar DryBag 5mm Allen key Art no. TC2702B Art no. TT9805B MOUNTING INSTRUCTIONS Fits ø25.4, ø28.6 and ø31.8 mm handlebars.
