LED Diagnostics:

Red (DC) Green (AC)
ON ON
ON OFF
OFF ON
OFF OFF

Enclosure Dimensions:

13"H x 13.5"W x 3.25"D
3.25" 1.1875"
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IILPS5C24X
Power Supply Status
Normal operating condition.
Loss of AC, Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or missing stand-by battery. No DC output.
3.25"
1.1875"
0
0 0 .75" 1.5"
0
.81"
1.4"
6.5"
11.66"
12.1"
13"
E11E
TOP ONLY
6.25"
12.5"
11" 11.75" 0 1.1875"
1.4"
5.5"
3.25"
