INSTRUCTION MANUAL
DC Folder 1
DC-F 1
Be sure to read this manual prior to use.
Please leave this manual at the site of use for easy reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-F 1 and is the answer not in the manual?

Questions and answers

John Haskell
May 29, 2025

Says documents in folder lower exit. Remove documents. There are no documents or paper scraps anywhere. Is there a bad sensor? Duplo is brand new

0

Related Manuals for Duplo DC-F 1

Summary of Contents for Duplo DC-F 1

  • Page 1 INSTRUCTION MANUAL DC Folder 1 DC-F 1 Be sure to read this manual prior to use. Please leave this manual at the site of use for easy reference.
  • Page 2 Introduction Thank you for your purchase of the Duplo DC-F1. To ensure safe and efficient prolonged use of this unit, read and thoroughly understand this manual before using this unit. After using this manual, be sure to keep it in a handy place to reference.

  • Page 4: Table Of Contents

    Contents Introduction Provisions of WEEE Contents Notes on Safety (Please Read and Observe) Locations of warning labels Chapter 1 Before Use 1．Part Names and Their Functions………………………………………12 Overall appearance (DC-F1)……..…………………………………………………12 Inside of DC-F1 ……..………………………………………………………………13 Overall appearance (DC-SC1) ………………….…………………………………14 2．Part Names and Their Functions on the Control panel……………15 Control Panel …………………………………………………………………………15 3．Description on the LCD …………………………………………………17 Display Screen(stand-by screen) …………………………………………………17...
  • Page 5 2-3. Confirming the entered JOB (only in manual mode)…….…………………37 2-4. Processing paper by selecting JOB (only in manual mode)…………39 2-5. Changing JOB setting (only in manual mode).…………………………41 2-6. Using log function (only in manual mode)………………………………44 2-7. Returning to previous operation (only in manual mode)..……………46 2-8.

  • Page 6: Notes On Safety (Please Read And Observe)

    Notes on Safety (Please Read and Observe) Safety Precautions Various symbols and pictures are used in this manual and on the stickers affixed to the machine. These symbols and pictures provide warnings and instructions to prevent danger to you or other personnel, and to prevent damage to office property.
  • Page 7 ● Installation location WARNING ● Do not place the machine in a humid or dusty area. →It may cause a fire or electric shock. ● Do not place the machine in a humid place or area exposed to water. →Insulation may deteriorate causing a fire or electric shock. ●...
  • Page 8 ● Power supply and power supply cord WARNING ● Use only the specified voltage. Never plug multiple cords into a single outlet. →It may cause a fire or electric shock. ● Be sure to remove dust on the power plug and/or the outlet. Using these without removing dust may have minute electric current flow to the surface due to the humidity and cause a fire due to the heat.
  • Page 9 ● Long periods of disuse CAUTION ● Leave the power supply cord unplugged when the machine is not used for a long period (i.e. during vacation). →Insulation may deteriorate and cause an electrical fire. ●Liability for damaged paper CAUTION ● We shall not be liable for any damage to or dirt on envelopes or enclosures resulting from the use of the machine as well as any secondary damage.

  • Page 10: Locations Of Warning Labels

    Locations of warning labels Keep the WARNING and CAUTION labels clean at all times. If labels become damaged or come off, replace them with new ones. ●DC Folder 1 (DC-F1) １ ２ NO. Part No. Name Q’ty M7-T3030 WARNING P9-T3100 CAUTION - 9 -...
  • Page 11 ●DC Straight Conveyer 1 (DC-SC1) Note: The DC-SC1 is connected to the DC-F1 and is not included in the DC-F1. １ Part No. Name Q’ty M7-T3030 WARNING - 10 -...

  • Page 12: Chapter 1 Before Use

    Chapter 1 Before Use - 11 -...

  • Page 13: 1．Part Names And Their Functions

    1. Part Names and Their Functions ●Overall appearance (DC-F1) Name Function Control panel Displays operations and statuses. Lock lever Use this to remove the paper jam. Skew adjust knob Adjusts horizontal fold skew. Exited paper board Paper without folds is exited on this board. Press the ‘I’...

  • Page 14: Inside Of Dc-F1

    ●Inside of DC-F1 ●Fold 1 area Name Function Fold knife 1 Folds paper. (fold position 1) Fold roller 1 Folds paper and feeds it. Fold roller 2 Folds paper and feeds it. ●Fold 2 area Name Function Fold knife 2 Folds paper.

  • Page 15: Overall Appearance (Dc-Sc1)

    ●Overall appearance (DC-SC1) Note: The DC-SC1 is connected to the DC-F1 and is not included in the DC-F1. Name Function Manual slot (option) Insert paper here when folding paper individually. Top cover Open this to remove the paper jam. - 14 -...

  • Page 16: 2．Part Names And Their Functions On The Control Panel

    2. Part Names and Their Functions of the Control panel ●Control panel PQRS WXYZ Name Function Displays the status of the unit. LCD panel Displays message when an error or paper jam occurs. F key Switches to function selecting display. RETURN key Switches the current screen to the previous one.
  • Page 17 PQRS WXYZ Name Function NUMBER key Press to enter JOB. SET key Press to fix switching function or JOB entry. Press to cancel JOB entry or clear the number of current CLEAR key processed sheet to ‘0’. - 16 -...

  • Page 18: 3．Description On The Lcd

    3.Description on the LCD Registration data, operation mode, operation status and error messages are displayed on the LCD panel. ●Display Screen (stand-by screen) 01：DUPLO01 StopPos:XXX.X ㎜ fin. Sht Name Function JOB No. Displays JOB No. currently selected. JOB name Displays JOB name currently selected. Displays stacker upper guide position (finished paper size) Stopper position only when stacker is connected to the system.

  • Page 19: Function Mode Display

    ●Function mode display Select menu Retrieve JOB Enter JOB Settings Manual mode System Cleaning Mode Return Name Function Retrieve JOB Retrieves registered JOB. Enter JOB Enters JOB. Sets unit, paper ejected position, fold position correction, fold Settings cancel while JOB processing on DC (only in DC mode). Manual mode Switches manual mode status (ON/OFF).

  • Page 20: 4．Paper Handling

    ４.Paper Handling 4-1. About Papers ● Flatten paper with folds or wrinkle or curls before using. ● Completely dry print ink on the paper before using. CAUTION Using paper with print ink not dried completely will stain fold roller and this will cause trouble such as stain on the paper.

  • Page 21: Paper Size Limit After Folding

    4-3. Paper size limit after folding Paper size to be fed and fold dimension are different according to fold type. Before starting to fold the paper, confirm paper size and fold dimension. ● No fold (Fold zero) Paper Length When using DC-SC: 85mm - 650mm When using DC-CC 85mm –...
  • Page 22 ● Fold type: Z, C (Fold twice) Paper Length 170mm - 650mm Paper Width Fold Fold 48mm - 370mm 85mm- 85mm- 85mm- * Z-fold: 42.5mm can be entered for Fold 1, and 85.0mm can be entered for Fold 2. ● Fold type: Double Parallel (Fold 3 times) Paper Length 212.5mm - 650mm...

  • Page 23: 5．Turning Power On/Off

    5. Turning Power ON/OFF There are several combinations of connecting this unit. Before turning on this unit, first turn on the downstream unit and then turn on this unit. 5-1. Turning power ON 1. Insert the female side of the power supply cord into the inlet.

  • Page 24: 6．Connecting With Other Units

    6. Connecting with Other Units 6-1. When connecting with other units The DC-F1 cannot be used by itself. When feeding paper to this unit, you need other unit to be connected such as DC machine (DC-645/DC-615/DC-445) and DC-SC1. Please use the DC-F1 in appropriate combinations for your environment with reference to the system configuration below.

  • Page 25: 7．Switching Input Unit

    7. Switching Input Unit You can select input unit, mm mode or inch mode. This section describes the procedures to switch it from mm mode to inch mode. Default setting of input unit is mm mode. 7-1. Selecting input unit 1．Confirm that the LCD panel displays stand-by screen.

  • Page 26: Notes For Input Unit

    5. Press the CURSOR key (Down) several times to select ‘Select unit’. Settings Select unit inch 6. Select ‘inch’ using the CURSOR keys (Right/Left) and press the SET key. Right illustration: When switching input unit to Settings ‘inch’. Select unit inch 7.
  • Page 27 - 26 -...

  • Page 28: Chapter 2 Basic Operations

    Chapter 2 Basic Operations - 27 -...

  • Page 29: 1．Supported Fold Type

    1. Supported Fold Type 1-1. Fold type This unit can perform 6 types of fold, V-fold, 2V-fold, Z-fold, C-fold, Gate fold and Double Parallel-fold. This section describes fold types that the unit can perform. Fold type Fold 2 position Fold 1 position Before folded V-fold ―...

  • Page 30: 2．Manual Insertion Function (Option)

    2. Manual Insertion Function (Option) As described in ‘6. Connecting with Other Units’ in DC-F1 Paper chapter 1, this unit cannot be used by itself. To feed paper in the unit, the paper should be inserted from the manual slot on the DC-SC1. Also, the paper should be processed sheet by sheet with attention to fold direction, right side/other side/leading edge/rear edge of the paper.

  • Page 31: Entering Job On The Control Panel (Only In Manual Mode)

    4. Press the SET key to fix ‘Manual mode’. Select menu Enter JOB Settings Manual mode 5. ‘Manual mode switching screen’ appears on the LCD panel. Select ‘ON’ using the CURSOR keys (Right/Left) and press the SET key. Manual mode 6.
  • Page 32 2. Press the F key to display ‘Select menu’ screen on the control panel. Select menu Retrieve JOB Enter JOB Settings 3. Press the CURSOUR key (Down) several times to select ‘Enter JOB’. Select menu Retrieve JOB Enter JOB Settings 4.
  • Page 33 7. Press the SET key. ‘JOB name entering screen’ appears. JOB 01 entry 1/7 Enter JOB name 8. Enter JOB name using the NUMBER keys. Up to 13 characters can be entered. Refer to the table below for available characters. 9.

  • Page 34: Selecting Fold Type

    11. Enter paper length (mm) you desire to save using the NUMBER keys and then press the SET key. Example: When ‘420 mm’ is entered. JOB 01 entry 2/7 Length 420.0mm (96.0-650.0) ● Selecting fold type ● V-fold (1V) ①Select ‘V-fold (1v)’ using the CURSOR keys (Right/Left) and then press the SET key.

  • Page 35: C-Fold

    ②Enter the dimension of Fold 1 using the NUMBER keys and then press the SET key. Right illustration: When ‘210.0mm’ is entered. JOB 01 entry 4/7 Fold1 210.0mm (42.5-377.5) ● C-fold ①Select ‘C-fold’ using the CURSOR keys (Right/Left) and then press the SET key. Right illustration: When ‘C-fold’...

  • Page 36: Gate Fold

    ②Enter the dimension of Fold 1 using the NUMBER keys and then press the SET key. Right illustration: When ‘140.0mm’ is entered. JOB 01 entry 4/7 Fold1 140.0mm (42.5-335.0) ③Enter the dimension of Fold 2 using the NUMBER keys and then press the SET key. Right illustration: When ‘280.0mm’...

  • Page 37: Double Parallel

    ●Double Parallel ①Select ‘Double Parallel’ using the CURSOR keys (Right/Left) and press the SET key. Right illustration: When ‘Double Parallel’ is selected. JOB 01 entry 3/7 Sel FOLD Type ②Enter the dimension of Fold 1 using the NUMBER keys and then press the SET key. JOB 01 entry 4/7 Right illustration: When ‘107.0mm’...

  • Page 38: Confirming The Entered Job (Only In Manual Mode)

    12. When registering the data on JOB No.01, select ‘Overwrite JOB 01’ and press the SET key. When registering the data on different JOB No., JOB 01 entry 7/7 select ‘Save as different JOB no’ using the Overwrite JOB01 CURSOR keys (Up/Down) and then press the SET Save as different JOB no key.
  • Page 39 4. Select ‘Retrieve JOB no.’ and press the SET key. Retrieve JOB Retrieve JOB no. Retrieve JOB log Return 5. Saved JOB name is displayed. Retrieve JOB01 DUPLO01 2:〔No Data〕 3:〔No Data〕 6. Press the right CURSOR key to display the screen for confirming paper length.

  • Page 40: Processing Paper By Selecting Job (Only In Manual Mode)

    9. Press the STOP key. Stand-by screen appears. 01:DUPLO01 StopPos:XXX.X ㎜ fin.Sht 2-4. Processing paper by selecting JOB (only in manual mode) The following describes the procedures to process the paper by selecting JOB. 1. Confirm that the LCD panel displays stand-by screen.
  • Page 41 4. Press the SET key to fix ‘Retrieve JOB no.’. Retrieve JOB Retrieve JOB no. Retrieve JOB log Return 5. Saved JOB name is displayed. Retrieve JOB01 DUPLO01 2:〔No Data〕 3:〔No Data〕 6. Enter JOB number you desire to process using the CURSOR keys (Up/Down) or the NUMBER keys.

  • Page 42: Changing Job Setting (Only In Manual Mode)

    9. Set the paper in the manual slot on the DC-SC1. DC-F1 Paper DC-SC1 10. Press the TEST key. ‘in operating’ is displayed and operation starts. WXYZ 11. The paper is ejected to the DC-ST2. DC-F1 Paper Right illustration: When the DC-ST2 is connected. DC-ST2 2-5.
  • Page 43 2. Press the F key to display ‘Select menu’ screen on the LCD panel. Select menu Retrieve JOB Enter JOB Settings 3. Press the CURSOR key (Down) several times to select ‘Enter JOB’. Select menu Retrieve JOB Enter JOB Settings 4.
  • Page 44 7. JOB name entry screen appears. Correct JOB name using the NUMBER keys. Right illustration: When JOB name is changed to JOB 01 entry 1/7 A3 Z. Enter JOB name 01:A3 Z 8. Enter paper length (mm) you desire to save using the NUMBER keys and then press the SET key.

  • Page 45: Using Log Function (Only In Manual Mode)

    12, After setting is entered, when you desire to overwrite on the same JOB No., select ‘Overwrite JOB 01’ and press the SET key. JOB 01 entry 7/7 When you desire to save as different JOB No., Overwrite JOB01 select ‘Save as different JOB no’ using the Save as Different JOB no CURSOR keys (Up/Down) and press the SET...
  • Page 46 3. Press the SET key to fix ‘Retrieve JOB’. Select menu Retrieve JOB Enter JOB Settings 4. Press the down CURSOR key to fix ‘Retrieve JOB log’ and then press the SET key. Retrieve JOB Retrieve JOB no. Retrieve JOB log Return 5.

  • Page 47: Returning To Previous Operation (Only In Manual Mode)

    2-7. Returning to previous operation (only in manual mode) 1. To return to previous operation, press the RETURN key in the middle of JOB entry. Select menu Retrieve JOB Enter JOB Settings 2-8. Stopping JOB entry (only in manual mode) 1.

  • Page 48: Chapter 3 Application Operations

    Chapter 3 Application operations - 47 -...

  • Page 49: 1．Function Setting Mode

    1. Function Setting Mode 1-1. Using ‘Reject mode’ (only in DC mode) This mode is used when the unit interlocks with the DC machine (DC-645/DC-615/ DC445) and is used for JOB with no fold. The paper does not go through the decurl area and is ejected to the reject area.

  • Page 50: Using 'No Fold Mode' (Only In Dc Mode)

    5. Press the down CURSOR key to several times to select ‘Reject mode’. Settings Reject mode 6. Select ‘ON’ using the CURSOR keys (Right/Left) and press the SET key. Right illustration: When ‘Rejet mode’ is Settings changed to ‘ON’. Reject mode 7.
  • Page 51 2. Press the F key to display ’Select menu’ screen on the LCD panel. Select menu Retrieve JOB Enter JOB Settings 3. Press the down CURSOR key several times to select ‘Settings’. Select menu Retrieve JOB Enter JOB Settings 4. Press the SET key to fix ‘Settings’. Select menu Retrieve JOB Enter JOB...

  • Page 52: Using 'Precision Mode' (Only When Dc-Sc1 Is Connected)

    7. ‘Entering setting’ is displayed on the LCD panel and stand-by screen appears. 01:DUPLO01 StopPos:XXX.X ㎜ fin.Sht 1-3. Using ‘Precision mode’ (only when DC-SC1 is connected ) This mode used only when unit interlocks with machine (DC-645/DC-615/DC445). Use this mode when adjusting paper feed speed of DC machine and DC-F1 to enhance fold accuracy of light paper.
  • Page 53 4. Press the SET key to fix ‘Settings’. Select menu Retrieve JOB Enter JOB Settings 5. Press the down CURSOR key several times to select ‘Precision mode’. Settings Precision mode 6. Select ‘ON’ using the CURSOR keys (Right/Left) and press the SET key. Right illustration: When ‘Precision mode’...

  • Page 54: Chapter 4 Trouble Guide

    Chapter 4 Trouble Guide - 53 -...

  • Page 55: 1．Adjusting Fold Skew

    1. Adjusting Fold Skew Folding results vary even on the paper of the same size and fold skew may occur depending on paper type, thickness, print status, processing speed, etc. This unit corrects fold position in each mode individually. Correctable range is ±5mm. Fold correction dimension is cleared by turning the power off or selecting other function.

  • Page 56: Adjusting Vertical Fold Skew

    1-2. Adjusting vertical fold skew When folded paper edge is skewed vertically as Eject direction shown in the right illustration, correct by adjusting the fold position of the fold knife 1 and fold knife 2. Right illustration: Fold type is 1V. Fold skew 1.
  • Page 57 5. Press the down CURSOR key to select ‘Fold1-1 Adjust’ and enter fold correction dimension using NUMBER keys. Settings Right illustration: When ‘+1.0mm’ of fold correction Fold1-1 Adjust + 1.0mm dimension is entered for Fold 1. - 0.0 mm 6. Press the CURSOR key (Down) to select ‘Fold1-2 Adjust’...
  • Page 58 Fold 1 correction Fold 2 correction How to Fold type Fold state How to correct Fold type Fold state correct Gate-fold Gate-fold ①:long Enter + value. ②:long Enter + value. Eject Eject direction direction ① Enter - value. Enter - value. ①:short ②:short ②...

  • Page 59: 2．Error Messages

    2. Error Messages If paper feed error or abnormal operation occurs while operating, error status is displayed on the LCD panel. This section describes the procedures to deal with paper jam and other errors. 2-1. Messages for paper jam When paper jam occurs, the following messages appear on the LCD panel. (1) There is a paper remained and jammed in the unit.

  • Page 60: Error Display

    2-3. Error display When a paper jam or error occurs, the LCD panel will display illustration (flashes inside circles) and message. In such case, follow the procedures below to resolve the cause. ● Errors on DC-F1 and DC-SC1 Status and Display Countermeasures Status: Top cover is open.
  • Page 61 Status: Paper remains in the Paper in machine Paper in machine decurl area. Countermeasure: Remove the Remove document jammed paper in the decurl from decurl area area. The error is automatically cleared. Status: Paper remains in the Paper in machine Paper in machine reject area.
  • Page 62 Status: A paper jam has Paper in m occurred in the Fold 1 area J3:Fold1 area while processing. Remove document Countermeasure: Remove the from fold 1 area jammed paper in the Fold 1 area and press the STOP key to clear the error. Status: A paper jam has Paper in m J4:Fold 2 area...
  • Page 63 Status: No paper has been set Paper in machine in the manual slot while No paper processing. Countermeasure: Set paper in Set paper in the manual slot and press the manual slot STOP key to clear the error. Status: Motor lock has occurred in the anterior part of Paper in machine conveyer area while...
  • Page 64 ●Errors on connected units Status: Error has occurred in the DC machine. Paper in machine Countermeasure: Check the DC machine. DC is busy Check DC. Status: No communication with connected units. Paper in machine Ring com error Countermeasure: Check communication in the system. Check connection Paper in machine Status: Paper remains in the stacker.
  • Page 65 Status: Paper remains in the DC-CC1. Paper Countermeasure: Remove the jammed paper in the DC-CC1 Paper in cross machine and press the STOP key to clear the error. Remove document from cross area. Status: A paper jam has occurred in the DC-CC1. Paper Cross is busy Countermeasure: Remove the jammed paper in the DC-CC1...
  • Page 66 ●Serviceperson errors Status: A memory error has occurred in the stacker. STR Memory error Countermeasure: The error cannot be cleared. Contact serviceperson. Contact service person Status: A communication error has occurred. E00 Main panel Countermeasure: The error cannot be cleared. Contact serviceperson.
  • Page 67 ●Area names FOLD2 area Decurl area Knife2 area Exit area Conveyer area R Conveyer area F FOLD1 area Knife1 area Reject area DC-ST2 DC-F1 DC-ST1 - 66 -...

  • Page 68: 3．When A Paper Jam Has Occuurred

    3. When a Paper Jam Has Occurred When a paper jam has occurred and the unit has stopped, the LCD panel displays the paper jam area. Follow the procedures below to remove the jammed paper. WARNING When removing the jammed paper, make sure that the unit fully stops. If it is hard to remove the jammed paper from the unit, use pliers for removing.
  • Page 69 ■ If the document cannot be removed with the procedure mentioned, follow the procedures below to remove it. 1. Open the top cover on the DC-SC1. Top cover DC-F1 DC-SC1 2. Remove the jammed document in the conveyer Paper area F. If it is not removed easily, use a tool such as pliers to remove it.

  • Page 70: When A Paper Jam Has Occurred In Conveyer Area R

    3-2.When a paper jam has occuured in conveyer area R When a paper jam has occurred in the posterior part of DC-SC1, “J2 Conveyer R” ‘Remove document from conveyer” error is displayed and paper jam area flashes on the LCD panel. Remove the document with the following procedures.

  • Page 71: When A Paper Jam Has Occurred In The Fold 1 Area

    2. Remove the jammed document in the conveyer area R. If it is not removed easily, use a tool such as pliers to remove it. 3. Close the top cover on the DC-SC1. Top cover DC-F1 DC-SC1 4. Press the STOP key to clear the error. The unit is reset and the error message is cleared.
  • Page 72 2. Lift the lock lever to open the FOLD2 area. FOLD2 area Lock lever 3. Remove the jammed document in the Fold 1 area in the direction of the arrow. Paper 4. Close the ‘FOLD2 area’. FOLD2 area 5. Press the STOP key to clear the error. The unit is reset and the error message is cleared.

  • Page 73: When A Paper Jam Has Occurred In The Fold 2 Area

    3-4. When a paper jam has occurred in the Fold 2 area When a paper jam has occurred in the FOLD2 area of DC-F1, “J4:Fold2 area” “Remove document from fold 2 area” error is displayed and paper jam area flashes on the LCD panel. Remove the document with the following procedures.

  • Page 74: When A Paper Jam Has Occurred In The Decurl Area

    5. Press the STOP key to clear the error. 2 ABC 5 JKL WXYZ 3-5. When a paper jam has occurred in the decurl area When a paper jam has occurred in the Decurl area of DC-F1, “J5:Decurl area” “Remove document from decurl area”...
  • Page 75 4. Remove the jammed document in the decurl area in the direction of the arrow. Paper 5. Install the press roller and fasten the knob. 6. Close the top cover by holding the handle. Handle Top cover 7. Press the STOP key to clear the error. The unit is reset and the error message is cleared.

  • Page 76: When A Paper Jam Has Occurred In The Exit Area

    3-6. When a paper jam has occurred in the exit area When a paper jam has occurred in the Exit area of DC-F1, “J6:Exit area”” Remove document from exit area” error is displayed and paper jam area flashes on the LCD panel. Remove the document with the following procedures.

  • Page 77: When A Paper Jam Has Occurred In The Reject Area

    5. Press the STOP key to clear the error. The unit is reset and the error message is cleared. 2 ABC 5 JKL WXYZ 3-7. When a paper jam has occurred in the reject area When a paper jam has occurred in the reject area of DC-F1, “J7:Reject area” ”Remove document from reject area”...

  • Page 78: When A Paper Jam Has Occurred In The Manual Slot

    3-8. When a paper jam has occurred in the manual slot When a paper jam has occurred in the manual slot of DC-SC1, “J8 Man. PF error” “Remove document from manual slot” error is displayed and paper jam area flashes on the LCD panel. Remove the document with the following procedures.
  • Page 79 5. Press the STOP key to clear the error. The unit is reset and the error message is 2 ABC cleared. 5 JKL WXYZ - 78 -...

  • Page 80: 4．Trouble Shooting

    4. Troubleshooting 4-1. If trouble occurs If trouble occurs, find the same phenomenon and message in the following table and deal with it before contacting our serviceperson. If the problem still persists, then contact our serviceperson. 4-2. Contacting serviceperson 1. Note the error code. 2.
  • Page 81 Is paper fold dimension entered Confirm that the fold correctly? dimension is entered correctly. Vertical fold skew occurred. Was the paper type (paper Use the paper before change. quality, paper thickness) changed while processing? - 80 -...

  • Page 82: Chapter 5 Maintenance

    Chapter 5 Maintenance - 81 -...

  • Page 83: 1． Daily Maintenance

    1. Daily Maintenance ● How to maintain the unit Check the unit periodically to maintain its performance. WARNING Remove power plug. ● Before cleaning, be sure to turn the power off, wait until the unit cools off and unplug the power cord. Otherwise, fire or electric shock may occur.

  • Page 84: 2． Cleaning

    2. Cleaning When this unit processes the paper output from digital color printer, toner sometimes attaches on the surface of conveyer rollers. And if toner accumulates, the paper may get dirty with the toner or it may cause fold skew. At times like this, clean the conveyer rollers according to the following procedures.
  • Page 85 5. Open the top cover by holding the handle. Handle Top cover 6. Wipe off the dirt on the conveyer rollers using a dry Conveyer roller and soft cloth or cloth tightly wrung out of water. Wipe CAUTION Never use alcohol or solvent cleaner. Caution It may tarnish or damage the exterior finish.

  • Page 86: Chapter 6 Specifications

    Chapter 6 Specifications - 85 -...
  • Page 87 1.Specifications Model name DC-F1 Folder floor model Product type ①No fold (available only in DC mode) Fold types ②V fold ( in both directions) ③C fold ④Z fold ⑤Gate fold ⑥C-GATE (available only in DC mode) ⑦Double parallel fold ① ②...
  • Page 88 Minimum fold length 85mm Minimum fold interval 42.5mm Fold tolerance Shall be processed in crease width. Outfeed No stacking mechanism Need to be connected with DC-ST1, DC-ST2, DC-CC1 Control panel 64-dot x128-dot LCD Panel language Japanese English German French Italian Spanish Polish Russian...
  • Page 89 Mode name DC-SC1 Product type Sheet conveyer, floor model No feeding mechanism Feeding Takes up sheet exited from the upstream unit with conveying roller. Infeed paper size No fold: Width 48mm - 370mm Length 85mm - 650mm 1-fold: Width 48mm - 370mm Length170mm - 650mm 2-fold: Width 48mm - 370mm Length170mm - 650mm...
  • Page 90 4-1-6 Oyama, Sagamihara-shi, Kanagawa, 229-1180, Japan TEL: +81-42-775-3602 FAX: +81-42-775-3606 E-mail: info@duplo.com U3-Y1010 2009.2 - 89 -...
