INSTALLATION INSTRUCTIONS FOR PART 99-7352B

Hyundai Genesis Coupe 2013-up

KIT FEATURES

• ISO radio provision with pocket

• Painted Matte Black

KIT COMPONENTS

• A) Radio Panel • B) Radio Brackets • C) Pocket • D) (4) #8 x 3/8" Phillips screws

• E) (2) PC-7871 Panel Clips • F) (12) #8 x 1/2" Phillips screws

WIRING & ANTENNA CONNECTIONS (sold separately)

Wiring Harness: • 70-7304 Kia/Hyundai harness 2010-up • HYBL-04 Bluelink/Amp Interface

Antenna Adapter: • No antenna adapter required

APPLICATIONS

99-7352B

TOOLS REQUIRED

• Phillips Screwdriver • Small Flat Blade Screwdriver

• Panel Removal tool

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

Need help?

Do you have a question about the 99-7352B and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS FOR PART 99-7352B APPLICATIONS Hyundai Genesis Coupe 2013-up 99-7352B KIT FEATURES • ISO radio provision with pocket • Painted Matte Black KIT COMPONENTS • A) Radio Panel • B) Radio Brackets • C) Pocket • D) (4) #8 x 3/8” Phillips screws •...
Page 2: Dash Disassembly
99-7352B Dash Disassembly 1. Unclip and remove the shifter trim 5. Remove (4) Phillips screws panel. (Figure A) securing the factory gauges to the radio/climate control panel. 2. Unclip and remove the display trim (Figure E) panel above radio. (Figure B) 6.
Page 3: Kit Preparation
1. Attach the pocket assembly to the 1. Locate the factory wiring harness 4. Attach the provided (2) panel 99-7352B radio panel using the (4) clips to the upper legs and the (2) in the dash. Metra recommends #8 x 1/2” Phillips screws provided.
