INSTALLATION INSTRUCTIONS FOR PART 99-7318
APPLICATIONS
2005-2006 Kia Spectra 5
99-7318
KIT FEATURES
• DIN Head Unit Provision
• ISO DIN Head Unit Provision
KIT COMPONENTS
A) Radio Housing l B) ISO Brackets l C) ISO Trim plate
B
A
C
TOOLS REQUIRED:
Phillips Screwdriver • Small Flat Blade Screwdriver
1-800-221-0932
www.metraonline.com
